凯斯零件查询(8540) - CASE IH RECTANGULAR BALER (1/88-12/93) (18[A]) - WHEEL AND HUB ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
754 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
13542
|
[12] |
WHEEL BOLT,Hex, 9/16" - 18 x 1 1/8", HT
|
NH
9/16-18 x 1-1/8 wheel bolt Superseded by part number: 86628557
|
| 2. |
700707967
|
[2] |
RIM
|
CAS
WHEEL RIM, 14" Superseded by part number: 481344R91
|
| 3. |
711242
|
[2] |
BEARING CUP
|
CAS
outer Superseded by part number: 47923369
|
| 4. |
26930
|
[2] |
CAP
|
IH
HUB CAP Superseded by part number: 518842R1
|
| 5. |
7704208
|
[2] |
SLOTTED NUT
|
CAS
3/4-16 slotted hex nut Superseded by part number: 88886
|
| 6. |
26971
|
[2] |
WASHER
|
CAS
|
| 7. |
711507
|
[2] |
ROLLER BEARING,31.77 mm ID x 16.764 mm
|
IH
BEARING CONE, outer Superseded by part number: 84356153
|
| 8. |
6851646
|
[2] |
SPINDLE
|
HFI
|
| 9. |
844050
|
[2] |
SEAL
|
L
grease
|
| 10. |
713537
|
[2] |
ROLLER BEARING
|
CAS
BEARING CONE, inner Superseded by part number: 86512015
|
| 11. |
663558R1
|
[2] |
BEARING CUP
|
IH
inner Superseded by part number: 86512015
|
| 12. |
826255
|
[2] |
HUB
|
CAS
ASSEMBLY (includes cups)
|
