| 1. |
712158
|
[2] |
SPHERICAL BEARING,2" ID x 100 mm OD
|
L
SPHERICAL BEARING Superseded by part number: 47577203
|
| 2. |
714360
|
[4] |
FLANGED BEARING
|
IH
FLANGE, bearing
|
| 3. |
2401533
|
[1] |
CRANK
|
HFI
CRANK, stuffer
|
| 4. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
PAN, chute
|
| 5. |
2401573
|
[1] |
CHUTE ASSY.
|
HFI
SIDE, chute
|
| 7. |
2401561
|
[1] |
ROD
|
HFI
TILE ROD, wrapper
|
| 8. |
2401556
|
[1] |
UNIT
|
HFI
WRAPPER, left
|
| 10. |
2401557
|
[1] |
UNIT
|
HFI
WRAPPER, right
|
| 11. |
2401541
|
[1] |
LINK ASSY.
|
HFI
LINK, stuffer
|
| 12. |
50583
|
[4] |
FLANGED BEARING
|
IH
FLANGE, bearing Superseded by part number: 86979948
|
| 13. |
51318
|
[2] |
BEARING
|
IH
SPHERICAL BEARING Superseded by part number: 668718R92, 47577169
|
| 14. |
51200380
|
[2] |
FLANGE
|
CAS
FLANGE, bearing
|
| 15. |
50302
|
[1] |
SPHERICAL BEARING,25.4 mm ID x 52 mm OD x 30.96 mm
|
CAS
SPHERICAL BEARING Superseded by part number: 204807C91, 47577183
|
| 17. |
6857122
|
[3] |
BUSHING
|
HFI
BUSHING, 1" O.D. x 1-1/16" long
|
| 18. |
51200383
|
[1] |
BUSHING
|
CAS
1-3/4 x 14 gauge machinery bushing
|
| 19. |
2401577
|
[1] |
SPACER
|
HFI
SPACER (wire twister only)
|
| 20. |
2401531
|
[1] |
PLATE
|
HFI
TAB, lock
|
| 21. |
6857874
|
[2] |
SPECIAL NUT
|
HFI
SPECIAL NUT, use screw 708545, see below
|
| 22. |
6857866
|
[3] |
SPACER
|
HFI
SPACER, special
|
| 23. |
667925R91
|
[3] |
ROLLER BEARING,0.628" ID x 2" OD x 15 mm
|
IH
CYLINDRICAL BEARING Superseded by part number: 47577176
|
| 24. |
6856579
|
[2] |
PLATE
|
HFI
TAB, lock
|
| 25. |
2401552
|
[1] |
BUSHING
|
HFI
DOOR, chute Superseded by part number: 2243530, 2243530, HFI2401552
|
| 26. |
425-1520
|
[1] |
JAM NUT,Jam, 1 1/4"-12, G5
|
CAS
1-1/2-12 hex jam nut
|
| 27. |
2700107
|
[1] |
WOODRUFF KEY,3/8" x 1
|
HFI
3/8 x 1 Woodruff key Superseded by part number: 126-67
|
| 28. |
6849160
|
[4] |
BRONZE BUSHING,44.74mm ID x 50.93mm OD x 38.1mm L
|
CAS
BUSHING, bronze, 1-3/4 I.D. x 1-1/2" long
|
| 29. |
1700061
|
[1] |
BUSHING
|
HFI
BUSHING, bronze, 1" I.D. x 1" long
|
| 30. |
77065
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
CAS
1/8 NPTF zerk Superseded by part number: 80710
|
| 31. |
700101216
|
[2] |
KNIFE
|
HFI
KNIFE, plunger
|
| 32. |
52233
|
[3] |
BUSHING
|
CAS
5/8 x 14 gauge machinery bushing Superseded by part number: 51200381
|
| . . |
7701659
|
[3] |
BOLT,Hex, 5/8" - 11 x 2 1/2", Gr 5
|
CAS
5/8-11 x 2-1/2 hex cap screw grade 5 Superseded by part number: 280233
|
| . . |
701235
|
[2] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 hex cap screw grade 5
|
| . . |
70924864
|
[2] |
SCREW
|
CMI
1/2-13 x 2-1/4 hex cap screw grade 5 Superseded by part number: 50032
|
| . . |
873687
|
[2] |
BOLT,Hex, 5/8" - 11 x 2 1/4", Gr 8
|
HFI
5/8-11 x 2-1/4 hex cap screw grade 5 Superseded by part number: 280355
|
| . . |
873703
|
[1] |
BOLT,Hex, 5/8" - 11 x 2 3/4", Gr 8
|
HFI
5/8-11 x 2-3/4 hex cap screw grade 8 Superseded by part number: 426-1044
|
| . . |
700013
|
[3] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 round head square neck bolt grade 5
|
| . . |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 round head square neck bolt grade 5 Superseded by part number: 280430
|
| . . |
433-816
|
[16] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 round head square neck bolt grade 5 Superseded by part number: 280486
|
| . . |
68619
|
[4] |
BOLT,Round, 1/2" - 13 x 1 1/4", Grade 5
|
CAS
1/2-13 x 1-1/4 round head square neck bolt grade 5 Superseded by part number: 87868
|
| . . |
703132
|
[26] |
SERRATED SCREW
|
CAS
5/16-18 x 3/4 hex flange serrated screw Superseded by part number: 145913
|
| . . |
7883366
|
[2] |
SCREW,Hex Washer, 3/8" - 16 x 1/2"
|
CAS
3/8-16 x 1/2 hex washer head machine screw
|
| . . |
7883374
|
[8] |
SCREW,Hex Washer, 3/8" - 16 x 3/4"
|
CAS
3/8-16 x 3/4 hex washer head cap screw grade 5 Superseded by part number: 255918
|
| . . |
7883382
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
5/16-18 x 1 hex washer head cap screw grade 5 Superseded by part number: 87034804
|
| . . |
708545
|
[2] |
SET SCREW
|
HFI
1/2-13 x 2-1/2 cup point hex socket set screw, used with ref 21 Nut
|
| . . |
704700
|
[1] |
SUPPORT
|
NNA
5/8-11 hex center lock nut Superseded by part number: 230-42110
|
| . . |
704924
|
[3] |
NUT
|
CAS
5/8-11 hex top lock nut Superseded by part number: 85700693
|
