| 1. |
6853931
|
[2] |
BRACKET
|
HFI
GUIDE BRACKET
|
| 2. |
762435
|
[1] |
LOCK PIN,1/2" x 3", Slotted
|
HFI
Pin, 1/2" x 3", Slotted Superseded by part number: 438-13248
|
| 3. |
6853535
|
[1] |
PLUNGER
|
HFI
STOP, plunger
|
| 4. |
6853493
|
[1] |
ARM/LIFTING DEVICE
|
HFI
ARM
|
| 5. |
758110
|
[1] |
SPRING
|
CAS
|
| 6. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 7. |
866236
|
[1] |
CLEVIS COUPLING
|
HFI
YOKE END Superseded by part number: 87312625
|
| 8. |
NLS
|
[1] |
NO LONGER SERVICED
|
BAS
1/2 x 1-1/2 clevis pin
|
| 9. |
700101205
|
[1] |
LINK
|
HFI
ROD, stop, plunger
|
| 10. |
700101203
|
[1] |
BUSHING
|
HFI
19/32 I.D. x 7/32" long
|
| 11. |
700101202
|
[1] |
STOP
|
HFI
arm, plunger
|
| 12. |
700101201
|
[1] |
SHIELD
|
HFI
needle slot
|
| 13. |
6553614
|
[2] |
SPACER
|
CAS
1/4" long
|
| 14. |
6553606
|
[2] |
MOUNTING PARTS
|
HFI
PLATE, mounting
|
| 15. |
66498
|
[2] |
CLEVIS
|
CAS
|
| 16. |
700101883
|
[2] |
ROD
|
HFI
|
| 17. |
6853485
|
[2] |
FINGER
|
HFI
|
| 18. |
77818
|
[2] |
FITTING
|
CAS
1/4-28 zerk, spin drive thread Superseded by part number: 87414
|
| 19. |
7746472
|
[1] |
CONNECTOR, ELEC
|
HFI
1/8 NPTF x 3/8 tube port M/F connector Superseded by part number: 222-1602
|
| 20. |
6853196
|
[1] |
FRAME ASSY
|
HFI
SHUTTLE FRAME
|
| 21. |
6853469
|
[1] |
JACK
|
CAS
#18 JACK CHAIN
|
| 22. |
758268
|
[1] |
SPRING
|
CAS
tension
|
| 23. |
2700077
|
[1] |
LINE
|
HFI
GREASE
|
| 24. |
6853287
|
[2] |
KNOTTER
|
HFI
BRACKET, knotter
|
| 25. |
763300
|
[2] |
CLEVIS PIN
|
CAS
5/16 x 1 clevis pin Superseded by part number: 427-5112
|
| 26. |
6850689
|
[1] |
BLOCK
|
HFI
SUPPORT BLOCK
|
| 27. |
7758980
|
[1] |
SPRING
|
CAS
tension Superseded by part number: 700712484
|
| 28. |
7058993
|
[1] |
SPRING
|
CAS
|
| 29. |
7894470
|
[1] |
COUNTER
|
CAS
bale
|
| 30. |
6853451
|
[1] |
BRACKET
|
HFI
|
| 31. |
7745003
|
[6] |
GUIDE
|
L
FERRULE
|
| 32. |
51200861
|
[6] |
U-BOLT
|
BRR
5/16-18 thread
|
| 33. |
6853675
|
[1] |
ROD
|
CAS
|
| 34. |
863753
|
[1] |
PIN
|
CAS
5/8 x 1-3/4 clevis pin Superseded by part number: 22754R1
|
| 35. |
730804
|
[4] |
DOWEL,1/4" x 1/2"
|
CAS
PIN Superseded by part number: 37-148
|
| 36. |
6554034
|
[1] |
BUSHING
|
CAS
1-1/4" long
|
| 37. |
6853105
|
[2] |
MOUNTING PARTS
|
HFI
PIVOT MOUNTING, shuttle
|
| 38. |
866228
|
[1] |
CLEVIS COUPLING
|
HFI
CLEVIS
|
| 39. |
1661235
|
[2] |
NEEDLE
|
HFI
twine
|
| 40. |
95-81182
|
[1] |
WASHER,0.81" ID x 1.25" OD x 0.07" Thk
|
CAS
3/4 x 14 gauge machinery bushing
|
| 41. |
77065
|
[1] |
LUBE NIPPLE,1/8"-27 x .66 lg
|
CAS
1/8-27 x 11/16 special zerk Superseded by part number: 80710
|
| 42. |
51200254
|
[4] |
WASHER
|
CAS
|
| 43. |
7746464
|
[1] |
ELBOW
|
HFI
1/4-28 x 1/8 NPTF M/F x 90deg. elbow Superseded by part number: 219-402
|
| . . |
701235
|
[2] |
BOLT,1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 hex cap screw grade 5
|
| . . |
873380
|
[1] |
SCREW,Hex, 1/2" - 13 x 2", Full Thd
|
HFI
1/2-13 x 2 full thread hex cap screw grade 5
|
| . . |
7772049
|
[8] |
BOLT,Hex Serr, 5/16" - 18 x 1"
|
CAS
5/16-18 x 1 hex flange serrated screw Superseded by part number: 86512168
|
| . . |
7884414
|
[2] |
CAPSCREW,Button Hd, 3/8" - 16 x 1", Gr 8
|
CAS
3/8-16 x 1 hex socket button head cap screw grade 5
|
| . . |
413-1036
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-1/4", Gr 5
|
CAS
5/8-11 x 2-1/4 hex cap screw grade 5 Superseded by part number: 88556
|
| . . |
700013
|
[9] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
5/16-18 x 3/4 round head square neck bolt grade 5
|
| . . |
7700578
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 5/16" - 18 x 1", Gr 5
|
CAS
5/16-18 x 1 round head square neck bolt grade 5 Superseded by part number: 33-516
|
| . . |
7700065
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 x 3/4 round head square neck bolt grade 5 Superseded by part number: 280430
|
| . . |
700047
|
[4] |
BOLT
|
CAS
3/8-16 x 1 round head square neck bolt grade 5 Superseded by part number: 80280503
|
| . . |
700054
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1-1/4 round head square neck bolt grade 5 Superseded by part number: 86508773
|
| . . |
7700156
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
1/2-13 x 1-1/2 round head square neck bolt grade 5 Superseded by part number: 280420
|
| . . |
7701188
|
[1] |
BOLT,Hex, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 x 1-1/4 hex cap screw grade 5 Superseded by part number: 87670
|
| . . |
703223
|
[2] |
BOLT,Hex, 1/2" - 13 x 4 1/2", Gr 5
|
CAS
1/2-13 x 4-1/2 hex cap screw grade 5 Superseded by part number: 87996
|
| . . |
413-864
|
[2] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
1/2-13 x 4 hex cap screw grade 5 Superseded by part number: 86505993
|
| . . |
707018
|
[2] |
BOLT,#3, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
3/8-16 x 1-1/4 plow bolt grade 5 Superseded by part number: 118-140
|
| . . |
230-4215
|
[14] |
NUT,5/16"-18, GA
|
CAS
5/16-18 hex center lock nut
|
| . . |
704288
|
[4] |
LOCK NUT
|
CAS
1/2-13 hex center lock nut Superseded by part number: 230-4218
|
| . . |
495-11081
|
[5] |
WASHER,3/4", SAE
|
CAS
3/4 narrow plain washer Superseded by part number: 87381
|
| . . |
705681
|
[3] |
WASHER,1", SAE
|
CAS
1" narrow plain washer Superseded by part number: 87367
|
