纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6520[003]) - ROPS CAB-WINDSHIELD WASHER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79096260 | [1] | SUPPORT | LEC |
| 2. | 76004366 | [1] | SECURING STRAP | LECBELT |
| 3. | 79096265 | [1] | TANK | LECCONTAINER; Cap Not Serviced Separately |
| 4. | 79095451 | [4] | NOZZLE | LEC |
| 5. | 79095815 | [1] | HOSE,4.00 mm ID x 800.00 mm | LEC Superseded by part number: 19052980 |
| 6. | 79095816 | [3] | HOSE | LEC Superseded by part number: 19044986 |
| 7. | 79095817 | [2] | HOSE,4.00 mm ID x 3500.00 mm | LEC Superseded by part number: 19052980 |
| 8. | 79093048 | [2] | HYD CONNECTOR | LECFITTING C2664 Superseded by part number: 79097787 |
| 8. | 79097787 | [2] | TEE | LECFITTING D2664 |
| 9. | 16043334 | [3] | BOLT,Hex, M8 x 1.25 x 18mm, Cl 10.9, Full Thd | LEC Superseded by part number: 16043331 |
| 10. | 16100821 | [3] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 11. | 14496531 | [3] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8,15x17 Superseded by part number: 86624184 |
| 12. | 79013422 | [5] | CABLE TIE,145mm L | LECSTRAP, CABLE, 145mm L |
