神钢零件查询(F4HFE613A B004) - ENGINE 5801862189 - 47587179 TIER 4B (7/15-) (10.106.AA) - CAMSHAFT Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
648 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4899079 | [6] | SCREW,Hex Flg, M8 x 1.25 x 25 | TOR |
| 2. | 4896380 | [1] | DRIVEN GEAR | TOR |
| 3. | 4899068 | [2] | BOLT,Flng, M8 x 1.25 x 16mm | BAS |
| 4. | 4897457 | [1] | SUPPORT | TOR |
| 5. | 2854604 | [1] | CAMSHAFT | TORASSY, Incl 6,7 Superseded by part number: 504080211 |
| 5. | 2854604R | [1] | REMAN-CAMSHAFT | TOR Superseded by part number: 504080211R |
| 5. | 2854604C | [1] | CORE-CAMSHAFT | TORReturn Number |
| 6. | 4899080 | [1] | DOWEL,M6 x 8 L | TOR |
| 7. | NSS | [1] | NOT SOLD SEPARAT | CONCamshaft, Incl in 5 |
