HK40555
|
[1] |
ATTACHMENT
|
ATT
HYDRAULIC PICKUP LIFT KIT COMPLETE
|
| 1. |
7721798
|
[3] |
CABLE
|
CAS
TIE - cable
|
| 2. |
413-612
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 3. |
231-5146
|
[1] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 4. |
515-23254
|
[1] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Hose 1", Insul, 3/8" Bolt Superseded by part number: 9827902, 72187281
|
| 5. |
700704629
|
[2] |
HOSE
|
CAS
- hydraulic
|
| 6. |
7046063
|
[1] |
ELBOW
|
CAS
90 DEGREE ELBOW WITH .06 ORIFICE
|
| 7. |
218-483
|
[1] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 1/4" - 18 Male NPTF
|
CAS
90 DEGREE ELBOW Superseded by part number: 578384
|
| 8. |
700115583
|
[1] |
BUSHING
|
CAS
|
| 9. |
432-1016
|
[2] |
COTTER PIN,5/32" x 1"
|
CAS
5/32" x 1" Superseded by part number: 83903970
|
| 10. |
700119477
|
[1] |
LINK
|
CAS
ARM - mounting, cylinder
|
| 11. |
439-11032
|
[1] |
HEADED PIN,15.88mm OD x 50.8mm L
|
CAS
5/8 X 2 CLEVIS PIN
|
| 12. |
111-505
|
[1] |
CARRIAGE BOLT,Short NK, 1/2"-13 x 3 1/2", G5
|
CAS
BOLT, CARRIAGE, Short NK, 1/2"-13 x 3 1/2", G5
|
| 13. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 14. |
425-108
|
[1] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 15. |
700116648
|
[1] |
PIN
|
CAS
|
| 16. |
7075625
|
[1] |
CYLINDER
|
L
CYLINER - hydraulic Superseded by part number: 700726495
|
| 17. |
495-11066
|
[1] |
WASHER,5/8", SAE
|
CAS
5/8 NARROW PLAIN WASHER Superseded by part number: 87365
|
