HK40634
|
[1] |
BALE THROWER KIT COMPLETE
|
|
| 1. |
700112662
|
[2] |
ROD
|
CAS
WA
|
| 2. |
50061K
|
[9] |
SPACER,1" Tube x 3/4"
|
IH
|
| 3. |
396-21066
|
[10] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 4. |
232-53110
|
[4] |
FLANGE NUT,Flg, 5/8"-11
|
CAS
5/8-11 HFTLN GR/G Superseded by part number: 84180923
|
| 5. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 6. |
496-11041
|
[2] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 7. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 8. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 9. |
1662543
|
[2] |
CHAIN (AG)
|
CAS
CHAIN - welded (18 links)
|
| 10. |
S120261
|
[2] |
PIN
|
CAS
.148 X 2-3/4 HAIR PIN COTTER
|
| 11. |
1662519
|
[2] |
SHIELD
|
CAS
- bale chute
|
| 12. |
1662535
|
[2] |
PIN
|
CAS
- hinge
|
| 13. |
1662527
|
[1] |
ROD
|
CAS
PIN - chute
|
| 14. |
700112688
|
[1] |
CHUTE (DOWNWARD)
|
CAS
CHUTE - upper
|
| 15. |
700106235
|
[1] |
PIN
|
CAS
- hinge
|
| 16. |
700115574
|
[1] |
CHUTE ASSY.
|
CAS
CHUTE - lower
|
| 17. |
434-616
|
[10] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 18. |
231-4116
|
[2] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN GR/B Superseded by part number: 88902, E64197
|
| 19. |
413-1028
|
[1] |
BOLT,Hex, 5/8" - 11 x 1-3/4", Gr 5
|
CAS
5/8-11 X 1-3/4 C Superseded by part number: 9627896
|
| 20. |
700112651
|
[1] |
FRAME
|
CAS
- mounting
|
| 21. |
700106060
|
[1] |
SPACER
|
CAS
BUSHING - lower
|
| 22. |
701771
|
[1] |
SUPPORT
|
NNA
5/8-11 X 2-1/4 C Superseded by part number: 413-1036
|
| 23. |
231-5146
|
[8] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 24. |
495-21106
|
[1] |
WASHER,1"
|
CAS
1 HARDENED PLAIN WASHER Superseded by part number: 87374
|
| 25. |
700112673
|
[1] |
FRAME
|
CAS
- chute
|
| 26. |
413-816
|
[2] |
BOLT,Hex, 1/2" - 13 x 1", Gr 5
|
CAS
Superseded by part number: 87909, BN50282
|
| 27. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 28. |
425-108
|
[6] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 29. |
7827116
|
[2] |
ROLLER
|
CAS
PAD - rubber
|
| 30. |
700111507
|
[2] |
CLEVIS
|
CAS
- clip
|
| 31. |
7758253
|
[2] |
SPRING
|
CAS
- compression
|
| 32. |
425-1010
|
[4] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 33. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 34. |
231-5145
|
[6] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 35. |
378604
|
[4] |
SPACER
|
CAS
BUSHING
|
| 36. |
413-824
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 37. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 WIDE PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 38. |
700115573
|
[1] |
SHIELD
|
CAS
- lower
|
| 39. |
700112051
|
[2] |
TUBE
|
CAS
PIPE - cross
|
| 40. |
700112341
|
[2] |
STRAP
|
CAS
- link
|
