纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6650[007]) - AIR CONDITIONING-CONDENSER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
177 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79096055 | [1] | DRY BATTERY | LECBATTERY |
| 2. | 79096056 | [2] | FAN | LECELECTRIC FAN |
| 3. | 14496321 | [8] | WASHER | LEC |
| 4. | 10571479 | [8] | LOCK WASHER,M5 | LECWASHER, LOCK, M5 Superseded by part number: |
| 5. | 14197890 | [8] | NUT | LEC5x1,8 Superseded by part number: 14197894 |
| 6. | 10978021 | [8] | BOLT,Hex, M5 x 20mm, Cl 8.8, Full Thd | BHB Superseded by part number: |
| 7. | 14496621 | [4] | WASHER,10.5mm ID x 21mm OD x 2mm Thk | TTFM10 x 21 x 2 |
| 8. | 12577211 | [4] | LOCK NUT,M10 x 1.5mm Pitch, 12.30mm High, Cl 8, ZND | TTFNUT, LOCK, M10 x 1.5, Cl 8 Superseded by part number: 17152921 |
| 9. | 11098621 | [4] | BOLT,Hex, M10 x 45mm, Cl 8.8, Full Thd | TTFBOLT, Hex, M10 x 45, 8.8, Full Thd |
