日立零件查询（CD2000）014: CAMSHAFT AND VALVE Hitachi HOP online
广数供应链运营团队, 15 02月, 2025，浏览：
426 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 001. | 1125112013 | [1] | CAMSHAFT | C |
| 001. | 1125112491 | [1] | CAMSHAFT | |
| 004. | 1125511261 | [6] | VALVE; INL | A |
| 004. | 1125511614 | [6] | VALVE; INL | |
| 005. | 1125520851 | [6] | VALVE; EXH | A |
| 005. | 1125521082 | [6] | VALVE; EXH | |
| 007. | 9920614280 | [1] | BOLT; CM/SHF GEAR | M14X28 |
| 008. | 9098518503 | [1] | WASHER; CM/SHF GEAR | |
| 009. | 1125220372 | [1] | GEAR; CM/SHF | Z=36 |
| 012. | 9080555160 | [1] | KEY; CAM GEAR SET | |
| 053. | 1126210841 | [1] | SHAFT; ROCKER ARM | |
| 065. | 1125650020 | [24] | COLLAR; SPLIT | |
| 069(A). | 1125610510 | [6] | SPRING; VLV,OUTER | |
| 069(B). | 1125610720 | [6] | SPRING; VLV,OUTER | |
| 070(A). | 1125620320 | [6] | SPRING; VLV,INNER | |
| 070(B). | 1125610730 | [6] | SPRING; VLV,INNER | |
| 071(A). | 1125630331 | [12] | SEAT; SPR | A |
| 071(A). | 1125630591 | [12] | SEAT; SPR | A |
| 071(A). | 8976032390 | [12] | SEAT; SPR | |
| 071(B). | 9125632311 | [12] | SEAT; SPR | |
| 072. | 1125690170 | [12] | SEAL; VLV GUIDE | ALSO INCLUDED IN GASKET SET(ENG. & HEAD) |
| 075. | 9010658550 | [3] | BOLT; BRKT | |
| 076. | 9098514300 | [3] | WASHER; PL,BRKT | |
| 078. | 1126100452 | [12] | ARM; ROCKER | |
| 081. | 1126160380 | [12] | SCREW; ADJ,ROCKER ARM | |
| 083. | 9098445740 | [12] | NUT; ADJ SCREW,LK | M8 FLANGE |
| 092. | 1126280450 | [3] | BRACKET; ROCKER ARM | |
| 095. | 1095803350 | [6] | SPRING; ROCKER SHAFT | |
| 099. | 9081120250 | [2] | PIN; SPLIT,ROCKER ARM SHAFT | A |
| 099. | 0811220250 | [2] | PIN; SPLIT,ROCKER ARM SHAFT | |
| 101(A). | 1090701270 | [1] | BOLT; THRUST COLLAR | M12X57 |
| 101(B). | 1090002840 | [1] | BOLT; THRUST COLLAR | M14X16 |
| 101(C). | 0280808140 | [3] | BOLT; THRUST COLLAR | M8X14 FLANGE |
| 107(A). | 1125310640 | [1] | SHAFT; IDLE GEAR | A |
| 107(A). | 1125310990 | [1] | SHAFT; IDLE GEAR | |
| 107(B). | 1125310541 | [1] | SHAFT; IDLE GEAR | A |
| 107(B). | 1125310972 | [1] | SHAFT; IDLE GEAR | |
| 111(A). | 8943706880 | [1] | COLLAR; THRUST,IDLE GEAR | A |
| 111(A). | 8972097282 | [1] | COLLAR; THRUST,IDLE GEAR | |
| 111(B). | 1125350211 | [1] | COLLAR; THRUST,IDLE GEAR | |
| 112(A). | 1125232410 | [1] | GEAR; IDLE | Z=69-27 |
| 112(A). | 1125232410 | [1] | GEAR; IDLE | A Z=69-27 |
| 112(A). | 1125233460 | [1] | GEAR; IDLE | Z=69-27 |
| 112(B). | 1125232420 | [1] | GEAR; IDLE | Z=62 |
| 112(B). | 1125232420 | [1] | GEAR; IDLE | A Z=62 |
| 112(B). | 1125233470 | [1] | GEAR; IDLE | Z=62 |
