神钢零件查询(F4HFE613A B004) - ENGINE 5801862189 - 47587179 TIER 4B (7/15-) (10.400.AE[02]) - COOLANT HEATING LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
335 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2852923 | [3] | SCREW | TOR Superseded by part number: 16593025 |
| 2. | 2854072 | [2] | SEALING RING,Square, 5.16mm Thk x 50.17mm ID | TOR Superseded by part number: 504062710 |
| 4. | NSS | [1] | NOT SOLD SEPARAT | CONHYD CONNECTOR; Incl in 3 |
| 5. | 98405182 | [2] | DOWEL | TOR |
| 6. | 2852922 | [1] | ELBOW | TOR Superseded by part number: 504042847 |
| 7. | 4895392 | [2] | HEX SOCKET PLUG,M18 x 1.5 | TORASSY, Incl 8, 9 |
| 8. | 4895393 | [1] | O-RING,2.2mm Thk x 15.3mm ID | TOR |
| 10. | 4895080 | [1] | HEX SOCKET PLUG,M22 x 1.5 | TORASSY, Incl 11, 12 |
| 11. | NSS | [1] | NOT SOLD SEPARAT | CONPLUG; Incl in 10 |
| 12. | 4895082 | [1] | O-RING,19.3mm ID x 2.2mm Width | TOR Superseded by part number: 2854072 |
