凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (9-74) - HYDRAULIC PUMP ASSEMBLY, CONVERSION KIT - CONTINUED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
907 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-620
|
[2] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Hex, 3/8"-16 x 1 1/4", G5, Full Thd Superseded by part number: 72187207, 88011
|
| 2. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
7796378
|
[1] |
PUMP
|
HFI
- hydraulic (Includes key) Superseded by part number: 87448820
|
| 5. |
413-612
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 6. |
700121578
|
[1] |
LARGE PLATE
|
CAS
PLATE WA - pump, rear
|
| 7. |
700121576
|
[1] |
LARGE PLATE
|
CAS
PLATE WA, front
|
| 8. |
85-516
|
[2] |
SET SCREW,Sq Hd, 5/16"-18 x 1"
|
CAS
5/16-18 X 1 CPHSSS Superseded by part number: 88971
|
| 9. |
1662626
|
[1] |
SHEAVE
|
CAS
- drive, pump
|
