| 1. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN - roller, #50
|
| 2. |
47530
|
[1] |
LINK, CONNECTING
|
IH
LINK - connector, #50
|
| 3. |
38-31016
|
[2] |
PIN,5/32" x 1", Coiled
|
CAS
Superseded by part number: 280634
|
| 4. |
6131916
|
[1] |
BUSHING
|
CAS
|
| 5. |
700119805
|
[1] |
ARM
|
CAS
WA - lift Superseded by part number: 700163045
|
| 6. |
413-824
|
[3] |
BOLT,Hex, 1/2" - 13 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 87689, 72187216
|
| 7. |
495-21056
|
[4] |
WASHER,1/2"
|
CAS
1/2 HARDENED PLAIN WASHER Superseded by part number: 72187265, 80700
|
| 8. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 9. |
425-108
|
[7] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 10. |
700127961
|
[1] |
STOP
|
CAS
|
| 11. |
700124886
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA - 50B18
|
| 12. |
700119326
|
[1] |
FLANGE
|
CAS
|
| 13. |
433-816
|
[2] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 X 1 RHSNB Superseded by part number: 280486
|
| 14. |
591514R1
|
[1] |
CARRIAGE BOLT,1/2" - 13 x 2 3/4", Grade 5
|
IH
1/2-13 X 2-3/4 RHSNB Superseded by part number: 88955
|
| 15. |
700119328
|
[1] |
STRIPPER
|
CAS
- auger
|
| 16. |
256873
|
[4] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 17. |
433-628
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 X 1-3/4 RHSNB Superseded by part number: 86508775
|
| 18. |
496-11041
|
[10] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 19. |
492-11038
|
[9] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 20. |
425-106
|
[13] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 21. |
T27207
|
[6] |
FLANGED BEARING
|
CAS
FLANGE Superseded by part number: 617863R1
|
| 22. |
565672R92
|
[3] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING - spherical Superseded by part number: 84330041
|
| 23. |
495-11081
|
[1] |
WASHER,3/4", SAE
|
CAS
Superseded by part number: 87381
|
| 24. |
434-616
|
[7] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 25. |
433-620
|
[3] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 26. |
700124879
|
[1] |
AUGER
|
CAS
WA - left
|
| 27. |
700709464
|
[1] |
NUT
|
CAS
3/8 NUT PUSHON
|
| 28. |
700709466
|
[1] |
HANDLE
|
CAS
- crank
|
| 29. |
700119810
|
[1] |
CRANK
|
CAS
WA - pickup
|
| 30. |
700706024
|
[1] |
WASHER
|
CAS
SPACER
|
| 31. |
219-93
|
[1] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
| 32. |
700119327
|
[1] |
SPACER
|
CAS
- pivot
|
| 33. |
700127964
|
[1] |
LARGE PLATE
|
CAS
PLATE WA - pivot, left
|
| 34. |
710079
|
[2] |
BALL BEARING,12.738 mm ID x 25.4 mm OD x 12.7 mm
|
CAS
BUSHING - spherical
|
| 35. |
61424
|
[2] |
KEY
|
CAS
1/4 X 1-1/4 KEY - gib
|
| 36. |
700112405
|
[1] |
SCREW
|
CAS
- shoulder
|
| 37. |
700127958
|
[1] |
LARGE PLATE
|
CAS
PLATE
|
| 38. |
700127962
|
[1] |
LINK
|
CAS
ASSEMBLY (Includes item 34)
|
| 39. |
700127959
|
[1] |
ARM
|
CAS
WA - pivot
|
| 40. |
700115572
|
[1] |
SQ HOLE WASHER
|
CAS
- special
|
| 41. |
396-21066
|
[5] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 42. |
700127970
|
[1] |
BRACKET
|
CAS
WA
|
| 43. |
86132
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 50B17
|
| 44. |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
5/8-11 X 2-3/4 C Superseded by part number: 88693
|
| 45. |
425-1010
|
[1] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 46. |
211623C91
|
[1] |
SPROCKET
|
IH
- idler, 50B17
|
