纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2110[029]) - TRANSMISSION-COMPONENTS New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
488 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 586675 | [1] | THRUST RING,55mm ID x 70mm OD x 5mm Thk | LECRING |
| 2. | 4962201 | [1] | CUP | LEC |
| 3. | 4977442 | [2] | HALF-RING | LECHALF RING |
| 4. | 4982111 | [1] | GEAR | LEC46T |
| 7. | 14464981 | [1] | O-RING,66.27mm ID x 2.887" OD x 3.53mm | LEC-231, Cl 7, 2.609" ID x .139" Thk (M66.27 ID x 3.53 Thk) Superseded by part number: 17290381 |
| 8. | 14465181 | [1] | O-RING,2.859" ID x 3.127" OD x 0.139" | LEC-233, Cl 7, 2.859" ID x .139" Thk (M72.62 ID x 3.53 Thk) |
| 9. | 14465981 | [1] | O-RING,98.02mm ID x 4.137" OD x 2.62mm | TTF0-RING 3,53x98,02 |
| 10. | 20063450 | [1] | BALL | LEC6,350 Superseded by part number: 20419320 |
| 11. | 20439480 | [1] | CYLINDRICAL ROLLER BEARING,55mm ID x 120mm OD x 29mm W | LECBEARING |
| 12. | 76008487 | [1] | RING | LEC |
| 13. | 79032456 | [1] | GEAR | LECAssy, 73T |
| 14. | 79051013 | [2] | SEAL,20.168mm OD x 1.143mm Width | LECSNAP RING - IN ALTERNATIVE Superseded by part number: 79086720 |
| 14. | 79086720 | [2] | SEAL,Split, 17mm ID x 19.8mm OD x 1.57mm Thk | LECSNAP RING - IN ALTERNATIVE |
| 15. | 79060757 | [1] | PIN,19.8mm OD x 98mm L | LEC |
| 5. | 14274534 | [10] | LOCK BOLT,Hex, M12 x 1.25 x 30mm, Cl 10.9, Full Thd | TTF Superseded by part number: 16326234 |
| 6. | 14457281 | [2] | O-RING,0.612" ID x 0.103" Width | TTF-114, Cl 7, .612" ID x .103" Thk |
