| 1. |
413-612
|
[2] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 2. |
231-5146
|
[22] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 3. |
83-1256
|
[2] |
SET SCREW,Hex Soc, 1/4"-20 x 3/8"
|
CAS
1/4-20 x 3/8 CPHSSS NP
|
| 4. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 280486
|
| 5. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 6. |
413-1040
|
[2] |
BOLT,Hex, 5/8" - 11 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 280233
|
| 7. |
396-21066
|
[4] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
- 5/8" bolt size 21/32" x 1 5/16" x .150", HDN Superseded by part number: 87613283
|
| 8. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 9. |
425-1010
|
[10] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 10. |
820963C91
|
[1] |
SPROCKET
|
IH
idler
|
| 11. |
7851082
|
[2] |
SPROCKET ASSY.
|
CAS
SPROCKET 40B10
|
| 12. |
433-612
|
[12] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 13. |
700136685
|
[1] |
SUPPORT
|
HFI
|
| 14. |
1790D
|
[1] |
CHAIN (AG)
|
IH
CHAIN roller #40, (10 foot bulk) Superseded by part number: 1790DX
|
| 15. |
320993R1
|
[2] |
SPACER,7/8" Tube x 1/2"
|
IH
|
| 16. |
217-1063
|
[2] |
TEE,3/8" - 18 Female x 3/8" - 18 Male Run
|
CAS
male run
|
| 17. |
218-1053
|
[2] |
ELBOW,90 Degree, 9/16"-18, 37 Degree x 3/8"-18, NPTF
|
CAS
90° Superseded by part number: 235131
|
| 18. |
700703817
|
[1] |
GAUGE
|
CAS
pressure
|
| 19. |
221-86
|
[2] |
REDUCER,Hex, 3/8" x 1/4" NPT
|
CAS
BUSHING reducer
|
| 20. |
217-1016
|
[2] |
ELBOW,3/8" - 18 Female x 3/8" - 18 Male
|
CAS
3/8 street Superseded by part number: 86521965
|
| 21. |
7892128
|
[1] |
VALVE
|
CAS
PUMP ASSEMBLY hydraulic
|
| 22. |
700136684
|
[1] |
SUPPORT
|
HFI
pump
|
| 23. |
121-108
|
[8] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 x 1 HWHMS
|
| 24. |
231-5145
|
[8] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 25. |
241-1314
|
[2] |
CHAIN LINK
|
CAS
LINK connector #40 Superseded by part number: 25195
|
| 26. |
61424
|
[2] |
KEY
|
CAS
gib, 1/4 x 1-1/4
|
| 27. |
700112643
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET, 46 tooth
|
| 28. |
700706300
|
[1] |
FLEXIBLE HOSE
|
CAS
HOSE - hydraulic
|
| 29. |
515-23159
|
[6] |
CLAMP,5/8", Insul, 3/8" Bolt
|
CAS
Superseded by part number: 86594406
|
| 30. |
700112641
|
[2] |
BOX
|
CAS
WA tension Superseded by part number: CAS700112641, CAS700112641, ZED700112641
|
| 31. |
700703825
|
[2] |
CLAMP
|
HFI
hose
|
| 32. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 33. |
A59457
|
[1] |
BRACKET
|
CAS
Superseded by part number: 847590
|
| 34. |
7852148
|
[2] |
RING, SNAP
|
IH
RING retainer
|
| 35. |
218-483
|
[2] |
ELBOW,90 Degree Elbow, 9/16" - 18 Male JIC x 1/4" - 18 Male NPTF
|
CAS
90° Superseded by part number: 578384
|
| 36. |
700108433
|
[1] |
SUPPORT
|
CAS
WA
|
| 37. |
700703899
|
[1] |
CYLINDER
|
CAS
hydraulic, tensioner
|
| 38. |
413-616
|
[4] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 39. |
700119498
|
[1] |
LARGE PLATE
|
CAS
PLATE rail
|
