纽荷兰零件查询(FD14E) - CRAWLER DOZER (1.2770[005]) - REAR TRANSMISSION-FINAL DRIVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
836 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 586726 | [44] | BOLT,Hex, M20 x 1.5 x 58mm | MOD |
| 2. | 590394 | [2] | NUT | LEC |
| 3. | 4959660 | [2] | GEAR | LEC Superseded by part number: 93201698 |
| 4. | 4959661 | [2] | GEAR | LEC |
| 5. | 13598521 | [44] | NUT | MKT20x1,5x20 |
| 6. | 24940180 | [2] | ROLLER BEARING,90mm OD x 33mm | LECBEARING 40x90 Superseded by part number: 24941640 |
| 7. | 24940300 | [2] | ROLLER BEARING,55mm ID x 120mm OD x 43mm W | LECBEARING 55x120 |
| 8. | 24940310 | [2] | ROLLER BEARING,70mm ID x 150mm OD x 51mm W | LECBEARING 70x150 |
| 9. | 24940320 | [2] | ROLLER BEARING,60mm ID x 150mm OD x 35mm W | LECBEARING 60x150 |
| 10. | 79005973 | [2] | SHAFT | LEC |
