凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (7-18) - SHIELDS ASSEMBLY - TOP Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
271 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
496-21034
|
[1] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 2. |
492-11031
|
[1] |
LOCK WASHER,5/16"
|
CAS
WASHER, LOCK, 5/16" Superseded by part number: 83990583
|
| 3. |
425-105
|
[1] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 4. |
700112277
|
[1] |
COVER
|
CAS
- knotter
|
| 5. |
256873
|
[3] |
BOLT,Hex Serr, 5/16" - 18 x 1/2", 5SPL, Full Thd
|
NH
|
| 6. |
700703259
|
[2] |
PLUG
|
CAS
- hole
|
| 7. |
700112249
|
[1] |
SHIELD
|
CAS
- top, plunger
|
| 8. |
231-5145
|
[11] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 9. |
121-115
|
[10] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 10. |
700119380
|
[1] |
SUPPORT
|
CAS
- shieled, right
|
| 11. |
700112258
|
[2] |
SUPPORT
|
CAS
PIVOT - outer
|
| 12. |
700108535
|
[2] |
SUPPORT
|
CAS
PIVOT - inner
|
| 13. |
700119492
|
[1] |
SHIELD
|
CAS
- top, knotter
|
| 14. |
700119379
|
[1] |
SUPPORT
|
CAS
- shield, left
|
