凯斯零件查询(8545) - CASE IH RECTANGULAR BALER (1/89-12/99) (6-38) - TWISTER PINION ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
493 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7813116
|
[1] |
PINION
|
CAS
GEAR - pinion
|
| 2. |
38-11624
|
[2] |
LOCK PIN,1/4" x 1 1/2", Slotted
|
CAS
PIN, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
|
| 3. |
7813124
|
[1] |
FRAME
|
CAS
ASSEMBLY - pinion (Includes Items 4 and 5)
|
| 4. |
7852528
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - bronze
|
| 5. |
52126
|
[2] |
BRONZE BUSHING
|
CAS
BUSHING - oilite
|
| 6. |
851923
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET - 25 tooth
|
| 7. |
7813249
|
[1] |
SHAFT
|
CAS
- pinion
|
| 8. |
219-93
|
[3] |
LUBE NIPPLE,90 Degree Elbow, 1/4" - 28 NPTF
|
CAS
Superseded by part number: 87415
|
