凯斯零件查询(8550) - CASE IH RECTANGULAR BALER (1/88-12/93) (12D) - IMPLEMENT DRIVELINE, INTERMEDIATE, ASSEMBLY, METAL SHIELDS Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
692 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700705833
|
[1] |
FORK
|
HFI
HALF ASSEMBLY (With yoke clutch) Sub.
|
| . . |
700709019
|
[1] |
JOINT
|
CAS
700709019 HALF ASSEMBLY (With yoke Clutch)
|
| . . |
700708995
|
[1] |
JOINT
|
CAS
AND 7010708995 HALF ASSEMBLY (With keyed yoke) Superseded by part number: 700720663
|
| 2. |
700703820
|
[1] |
UNIVERSAL JOINT
|
HFI
HALF ASSEMBLY (With keyed yoke) Sub. 700708995
|
| 3. |
700704380
|
[1] |
SHIELD
|
HFI
- outer
|
| 4. |
700704385
|
[1] |
YOKE
|
CAS
- keyed
|
| 5. |
806760
|
[2] |
KIT
|
CAS
JOURNAL REPAIR KIT Superseded by part number: 84355343
|
| 6. |
700704382
|
[1] |
FORK
|
CAS
YOKE AND TUBE
|
| 7. |
077032
|
[1] |
ZERK
|
|
| 8. |
700704377
|
[1] |
NYLON BEARING
|
CAS
BEARING - nylon, center Superseded by part number: 136418
|
| 9. |
700704378
|
[8] |
SHIELD
|
HFI
BEARING INSERT - shield Superseded by part number: 185746
|
| 10. |
700704381
|
[1] |
SHIELD
|
HFI
- inner
|
| 11. |
077040
|
[1] |
ZERK - 45 degrees
|
|
| 12. |
700705823
|
[1] |
ASSEMBLY
|
CAS
YOKE - clutch (With ball bearing and bronze bushing)
|
| 13. |
700704383
|
[1] |
FORK
|
CAS
YOKE AND SHAFT
|
| 14. |
7852726
|
[1] |
OIL SEAL
|
CAS
RETAINER RING Superseded by part number: 183442
|
| 15. |
7852817
|
[1] |
BUSHING
|
CAS
- bronze Superseded by part number: 7852114
|
| 16. |
7714926
|
[1] |
BALL BEARING,20 mm ID x 42 mm OD x 12 mm
|
CAS
BALL BEARING Superseded by part number: 84330089
|
