纽荷兰零件查询(FD14E) - CRAWLER DOZER (0.1660[003]) - RADIATOR ASSEMBLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
723 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 73156690 | [1] | RADIATOR | NH Superseded by part number: 73159485 |
| 2. | 73155721 | [1] | RADIATOR CAP | NHCAP |
| 3. | 73155719 | [136] | GROMMET | NHUPPER |
| 4. | 73153056 | [1] | DEFLECTOR | NHBAFFLE, UPPER |
| 5. | 73157117 | [136] | RIGID TUBE | NHTUBE |
| 6. | 73155405 | [1] | SPARE PART | NHTUBE |
| 7. | 73153057 | [1] | DEFLECTOR | NHBAFFLE, LOWER |
| 8. | 73155718 | [136] | GROMMET | NHLOWER |
| 10. | 79087893 | [1] | HOSE | LEC Superseded by part number: 76014938 |
| 11. | 70926917 | [2] | CLAMP | CMICLIP Superseded by part number: 86637978 |
