神钢零件查询(F4HFE613C B004) - ENGINE - 5801761363 - 47550882 (10/15-) (10.210.AF) - FUEL LINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
650 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 4894095 | [2] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 3. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 1 |
| 5. | 4894095 | [4] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 6. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 4 |
| 9. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 7 |
| 12. | 47545297 | [1] | ASSY, Incl 14, 15 | |
| 13. | 4890929 | [2] | O-RING,3mm Thk x 11mm ID | TOR |
| 14. | NSS | [1] | NOT SOLD SEPARAT | CONPipe, Incl in 13 |
| 16. | 9804260 | [1] | BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8 | NH |
| 19. | 9804260 | [1] | BOLT,Hex, M8 x 1.25 x 30mm, Full Thd, Cl 8.8 | NH |
| 21. | 4894095 | [2] | O-RING,2.5mm Thk x 8mm ID, 60 Duro | TOR |
| 22. | NSS | [2] | NOT SOLD SEPARAT | CONFITTING; Incl in 20 |
