纽荷兰零件查询(FD14E) - CRAWLER DOZER (0.0082[001]) - PISTON-ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
267 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 4802671 | [6] | PISTON | LEC+0,0 Superseded by part number: 1902586 |
| 1. | 4821412 | [6] | PISTON | LEC+0,6 |
| 2. | 4800402 | [6] | PISTON PIN | MODPIN +0,0 |
| 2. | 4800403 | [6] | PISTON PIN +0.2 | MODPIN +0,2 |
| 3. | 11060076 | [12] | CIRCLIP,M42, Int | MKTRING, LOCKING, M42, Int Superseded by part number: 16872976 |
| 4. | 4796208 | [6] | PISTON RING | MODS +0.0 Superseded by part number: 4855940 |
| 4. | 4796209 | [6] | SET OF PISTON RINGS +0.6 | MODPISTON RINGS +0,6 |
| 5. | 4712663 | [6] | OIL SCRAPER RING | MODPISTON RINGS +0,0 |
| 5. | 4712664 | [6] | OIL SCRAPER RING +0.6 | MODPISTON RINGS +0,6 |
| 6. | 8829266 | [6] | PISTON RING | MODS +0,0 |
| 6. | 8829393 | [6] | SET OF PISTON RINGS +0.6 | MODPISTON RINGS +0,6 |
| 7. | 1902586 | [6] | PISTON ASSY | LECKIT SEE PAGE 32 Superseded by part number: 1930742 |
| 7. | 1930234 | [6] | SET OF RINGS | MODKIT SEE PAGE 32 Superseded by part number: 1930753 |
