凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (09-10) - WAGON HITCH KIT, HK40244 KIT, TO BE ORDERED THROUGH WHOLEGOODS ONLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
688 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . . |
HK40244
|
[1] |
KIT wagon hitch, complete
|
|
| 1. |
6856157
|
[1] |
TUBE
|
HFI
hitch
|
| 2. |
700108697
|
[1] |
HITCH ASSY
|
HFI
TUBE outer front
|
| 3. |
413-896
|
[4] |
BOLT,Hex, 1/2" - 13 x 6", Gr 5
|
CAS
hex cap, 1/2-13 x 6 Superseded by part number: 86000020
|
| 4. |
80679
|
[4] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 5. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 6. |
700108699
|
[1] |
PLATE
|
HFI
clamp
|
| 7. |
700108692
|
[1] |
SUPPORT
|
HFI
mounting, rear
|
| 8. |
432-816
|
[1] |
COTTER PIN,1/8" x 1"
|
CAS
Superseded by part number: 80755
|
| 9. |
6557565
|
[1] |
PIN
|
CAS
|
