凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (05-06) - STUFFER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
898 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700703739
|
[2] |
BALL BEARING,30mm ID x 62mm OD x 23.8mm W
|
CAS
|
| 2. |
700108276
|
[2] |
SPACER
|
CAS
|
| 3. |
700108278
|
[4] |
WASHER
|
CAS
|
| 4. |
24172R1
|
[1] |
ADAPTER,1" NPT Male x 1/8" NPT Fem
|
CAS
BUSHING reducer
|
| 5. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
Superseded by part number: 80710
|
| 6. |
131-21
|
[2] |
LOCK NUT,1 1/8"-12, GB
|
CAS
light hex stop, 1-1/8-12
|
| 7. |
700108267
|
[1] |
SHAFT
|
CAS
WA
|
| 8. |
700703946
|
[1] |
CAM FOLLOWER
|
CAS
cam
|
| 9. |
85-15012
|
[1] |
SET SCREW,Sq Hd, 1/2"-13 x 3/4"
|
CAS
set cup point hex socket, 1/2-13 x 3/4 Superseded by part number: 86624113
|
| 10. |
700108277
|
[2] |
BOLT,Spcl, 1 1/8"-12 x 3.543"
|
CAS
special, 1-1/8-12 x 3.54
|
| 11. |
700124887
|
[1] |
COMPARATORLIP
|
CAS
STUFFER, WA
|
