| 1. |
700108393
|
[2] |
CHANNEL
|
HFI
chamber, side
|
| 2. |
700108424
|
[2] |
SUPPORT
|
HFI
WA
|
| 3. |
231-5148
|
[8] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 4. |
113-420
|
[4] |
BOLT,Hex, 1/2" - 13 x 3", Gr 5, Full Thd
|
CAS
|
| 5. |
6552558
|
[1] |
CHANNEL
|
CAS
cross, lower
|
| 6. |
6560601
|
[2] |
ROD
|
HFI
tension, WA
|
| 7. |
700117281
|
[5] |
DRIVE DOG
|
CAS
hay, WA
|
| 8. |
700707863
|
[5] |
SPRING
|
CAS
torsion
|
| 9. |
413-864
|
[5] |
BOLT,Hex, 1/2" - 13 x 4", Gr 5
|
CAS
SCREW hex cap, 1/2-13 x 4 Superseded by part number: 86505993
|
| 10. |
230-4118
|
[5] |
LOCK NUT,1/2"-13, GA
|
CAS
lock hex top, 1/2-13, GR/B
|
| 11. |
700108418
|
[5] |
WASHER
|
CAS
special
|
| 12. |
700703778
|
[5] |
BUMPER
|
CAS
|
| 13. |
700108394
|
[2] |
DOOR ASSY.
|
HFI
WA side
|
| 14. |
700108422
|
[4] |
CLIP
|
HFI
door
|
| 15. |
433-820
|
[18] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 87868
|
| 16. |
80679
|
[27] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 17. |
425-108
|
[27] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 18. |
433-828
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 3/4", Gr 5
|
CAS
round head square neck, 1/2-13 x 1-3/4 Superseded by part number: 88530
|
| 19. |
A28893
|
[4] |
BUSHING
|
CAS
SPACER
|
| 20. |
433-824
|
[6] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/2", Gr 5
|
CAS
Superseded by part number: 280420, 72187237
|
| 21. |
433-816
|
[3] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
BOLT round head square neck, 1/2-13 x 1 Superseded by part number: 280486
|
| 22. |
705541
|
[4] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened, plain, 1/2
|
| 23. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 24. |
492-11038
|
[2] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 25. |
425-106
|
[2] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 26. |
700108428
|
[2] |
RAIL
|
HFI
WA
|
| 27. |
700108433
|
[1] |
SUPPORT
|
CAS
WA
|
| 28. |
A59450
|
[1] |
WARNING SIGN
|
CAS
KIT, SMV Superseded by part number: 86590128
|
| 29. |
440-11012
|
[2] |
SCREW,Cross Pan Hd, #10-24 x 3/4"
|
CAS
Superseded by part number: 72187239, 86511922
|
| 30. |
492-11010
|
[2] |
LOCK WASHER,#10
|
CAS
Superseded by part number: 80684
|
| 31. |
225-14110
|
[2] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 32. |
A59457
|
[1] |
BRACKET
|
CAS
SUPPORT lamp Superseded by part number: 847590
|
| 33. |
700108401
|
[4] |
SUPPORT
|
CAS
|
| 34. |
425-1010
|
[4] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
