| 1. |
7770837
|
[1] |
BOLT,Sq Nk, 1/2" - 13 x 6", Gr 5, Full Thd
|
CAS
full thread round head square neck, 1/2-13 x 6
|
| 2. |
396-21066
|
[4] |
WASHER,16.66mm ID x 33.33mm OD x 4.27mm Thk
|
CAS
5/8" bolt size Superseded by part number: 87613283
|
| 3. |
700121083
|
[1] |
SPROCKET ASSY.
|
CAS
double, Includes: Ref. 17 and 18)
|
| 4. |
241-1315
|
[1] |
LINK, CONNECTING
|
CAS
Superseded by part number: 87034815
|
| 5. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
roller, No. 50, 10 foot bulk
|
| 6. |
700121080
|
[1] |
SPROCKET ASSY.
|
CAS
WA, 52 teeth
|
| 7. |
61747
|
[1] |
KEY
|
CAS
1/2 x 2-1/2, GIB
|
| 8. |
241-1715
|
[1] |
LINK,15.88mm Pitch
|
CAS
offset Superseded by part number: 86595276
|
| 9. |
211623C91
|
[1] |
SPROCKET
|
IH
sprocket idler, 17 teeth
|
| 10. |
413-1044
|
[1] |
BOLT,Hex, 5/8" - 11 x 2-3/4", Gr 5
|
CAS
hex cap, 5/8-11 x 2-3/4 Superseded by part number: 88693
|
| 11. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
Superseded by part number: 86729275
|
| 12. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 13. |
425-108
|
[2] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 14. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 15. |
700112234
|
[1] |
ANGLE
|
CAS
|
| 16. |
433-1032
|
[1] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 2", Gr 5
|
CAS
round head square neck, 5/8-11 x 2-1/2 Superseded by part number: 280742
|
| 17. |
100-21156
|
[1] |
SNAP RING,1.562", Int, #156
|
CAS
Superseded by part number: 9635563
|
| 18. |
666624R91
|
[2] |
BALL BEARING,16.26mm ID x 40mm OD x 18mm W
|
IH
cylindrical
|
| 19. |
705541
|
[1] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened, plain, 1/2
|
