凯斯零件查询(8555) - CASE IH RECTANGULAR BALER (1/90-12/99) (06-18) - SHUTTLE FRAME AND NEEDLE ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
270 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
51200861
|
[2] |
U-BOLT
|
BRR
|
| 2. |
700711131
|
[2] |
GUIDE
|
CAS
Superseded by part number: 84298727
|
| 3. |
700121485
|
[1] |
FRAME
|
HFI
shuttle, WA
|
| 4. |
231-5348
|
[4] |
FLANGE NUT,Flg, 1/2"-13
|
CAS
lock hex flange top, 1/2-13, GR/G Superseded by part number: 86521610
|
| 5. |
700111996
|
[2] |
NEEDLE
|
CAS
twine
|
| 6. |
326-864
|
[4] |
BOLT,Hex, 1/2" - 13 x 4", Gr 8
|
CAS
|
| 7. |
51200254
|
[4] |
WASHER
|
CAS
special
|
| 8. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 9. |
230-4215
|
[4] |
NUT,5/16"-18, GA
|
CAS
Center
|
| 10. |
496-21034
|
[4] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
