凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (2-12) - FLYWHEEL ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
131 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700123112
|
[1] |
FLYWHEEL
|
HFI
ASSEMBLY
|
| 2. |
6855555
|
[1] |
SLEEVE
|
CAS
- SHEAR
|
| 3. |
714634
|
[2] |
CONE
|
CAS
BEARING - CONE Superseded by part number: 648861
|
| 4. |
700706050
|
[1] |
O-RING
|
CAS
|
| 5. |
700710365
|
[1.5] |
SHIM
|
CAS
- FLYWHEEL, 0.008 / .003
|
| 6. |
700710366
|
[1] |
SHIM
|
CAS
- FLYWHEEL, 0.13 / .005
|
| 7. |
700123118
|
[1] |
HUB
|
CAS
- SHEAR
|
| 8. |
700710394
|
[1.5] |
SHIM
|
CAS
- FLYWHEEL CAP, 0.008 / .003
|
| 9. |
700710395
|
[1] |
SHIM
|
CAS
- FLYWHEEN CAP, 0.13 / .005
|
| 10. |
700113045
|
[1] |
LOCKING PLATE
|
CAS
TAB - LOCK
|
| 11. |
700708355
|
[2] |
SCREW
|
CAS
M16 X 2 X 40 C CLASS 10.9 NP Superseded by part number: 628-16040
|
| 12. |
700113044
|
[1] |
RETAINING PLATE
|
CAS
CAP - RETAINER
|
| 13. |
700710396
|
[1] |
SHIM
|
CAS
- FLYWHEEL CAP, 0.25 / .010
|
| 14. |
700710397
|
[2] |
SHIM
|
CAS
- FLYWHEEL CAP, 0.51 / .020
|
| 15. |
700710367
|
[1] |
SHIM
|
CAS
- FLYWHEEL, 0.25 / 0.10
|
| 16. |
700710369
|
[2] |
SHIM
|
CAS
- FLYWHEEL, 0.51 / .020
|
| 17. |
714626
|
[2] |
CUP
|
CAS
- BEARING Superseded by part number: 625743C1
|
| 18. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
NIPPLE, LUBE, 1/4"-28 NPT x .54" lg Superseded by part number: 87414
|
| 19. |
700710382
|
[1] |
SEAL
|
CAS
- OIL
|
| 20. |
7701899
|
[1] |
BOLT,Hex, 3/8" - 16 x 2 1/2", Gr 5
|
CAS
3/8-16 X 2-1/2 C Superseded by part number: 87936
|
| 21. |
704734
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
