凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (4-10) - LIGHTS, TAIL AND FLASHER ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
323 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
7883382
|
[6] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 2. |
704734
|
[12] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GRG Superseded by part number: 86521609
|
| 3. |
751487
|
[6] |
CLAMP
|
CAS
1/2 ID CLAMP Superseded by part number: 86632595
|
| 4. |
CAS745216
|
[1] |
CAP
|
CAS
|
| 5. |
700710062
|
[1] |
HARNESS
|
CAS
- LIGHTS
|
| 6. |
7883333
|
[1] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 X 1 HWHMS Superseded by part number: 121-108
|
| 7. |
704726
|
[1] |
LOCK NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GRG Superseded by part number: 232-5315
|
| 8. |
722470
|
[1] |
MOUNTING CLIP
|
CAS
TIE - NYLON Superseded by part number: 529070
|
| 9. |
7700065
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 10. |
700707010
|
[3] |
CLAMP
|
CAS
3/8 ID CLAMP Superseded by part number: 86572009
|
| 11. |
700708036
|
[2] |
SIDE LAMP ASSY
|
IH
LIGHT - FLASHER (Includes item 15) Superseded by part number: 130609
|
| 12. |
751628
|
[2] |
CLAMP
|
CAS
1/4 ID CLAMP Superseded by part number: 675162
|
| 13. |
700123423
|
[1] |
CHANNEL
|
CAS
|
| 14. |
700706634
|
[1] |
STOP LIGHT
|
IH
LIGHT - TAIL
|
| 15. |
700711749
|
[2] |
LENS
|
CAS
- FLASHER Superseded by part number: 71193862
|
