凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (7-12) - KNOTTER PLATFORM AND SHIELDS ASSEMBLY, SERIAL NO. CFH0068109 AND ON Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
119 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700123862
|
[2] |
SHIELD
|
CAS
CAPS WA - END
|
| 2. |
700123472
|
[1] |
FUNNEL
|
CAS
FRAME WA - LEFT
|
| 3. |
705525
|
[2] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 4. |
700123902
|
[1] |
SHIELD
|
CAS
|
| 5. |
700123473
|
[1] |
FUNNEL
|
CAS
FRAME WA - RIGHT
|
| 6. |
7883325
|
[16] |
BOLT,Hex, 5/16" - 18 x 3/4", Gr 120M
|
CAS
5/16-18 X 3/4 HWHMS Superseded by part number: 121-115
|
| 7. |
231-5145
|
[22] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
5/16-18 HFSLN GR/F Superseded by part number: 72187067, 145458
|
| 8. |
7883333
|
[6] |
BOLT,Hex, 5/16" - 18 x 1", Gr 120M
|
CAS
5/16-18 X 1 HWHMS Superseded by part number: 121-108
|
| 9. |
6854301
|
[1] |
PIN
|
CAS
- HINGE
|
| 10. |
700123864
|
[1] |
SHIELD
|
CAS
- KNOTTER, TOP
|
| 11. |
7700065
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
3/8-16 X 3/4 RHSNB Superseded by part number: 280430
|
| 12. |
700123910
|
[1] |
PLATFORM
|
CAS
ASM. (Includes Safety-Walk)
|
| 13. |
6849178
|
[1] |
WALL
|
CAS
SAFETY - WALK (10 FOOT)
|
| 14. |
700704838
|
[6] |
SCREW
|
CAS
#10-32 X 1/2 CRPHMS GR2 Superseded by part number: 86625206
|
| 15. |
705004
|
[6] |
LOCK WASHER
|
CAS
#10 L Superseded by part number: 80684
|
| 16. |
705640
|
[6] |
WASHER
|
NNA
#10 PLAIN WASHER Superseded by part number: 495-31022
|
| 17. |
700710676
|
[6] |
CONTAINER
|
CAS
MOUNTING - LATCH Superseded by part number: 1960763C3
|
| 18. |
1705912
|
[8] |
SCREW,#8 - 18 x 1/2"
|
CAS
#8-18 X 1/2 SRTHTFTS Superseded by part number: 19-1027
|
| 19. |
700710675
|
[6] |
STUD
|
CAS
- LATCH Superseded by part number: 1960762C1
|
