纽荷兰零件查询(FD14E) - CRAWLER DOZER (93.4800[001]) - ANGLE MOLDBOARD (HA) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
989 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79089608 | [1] | MOLDBOARD | LECANGLE MOLDBOARD (HA) Superseded by part number: 76028856 |
| 2. | 8294273 | [1] | CUTTING EDGE | LECEND BIT - RIGHT |
| 3. | 8294274 | [1] | CUTTING EDGE | LECEND BIT - LEFT |
| 4. | 8296247 | [1] | BRACKET | LECBALL SOCKET Superseded by part number: 11422331, 80280248, 8273213 |
| 5. | 8273530 | [12] | SCREW,Sq Hd, M20 x 1.5 x 72mm | LEC Superseded by part number: 8289500 |
| 6. | 12164333 | [32] | NUT,M20 x 1.5, Cl 12 | LEC Superseded by part number: 86015195 |
| 7. | 14497131 | [32] | WASHER,21mm ID x 37mm OD x 3mm Thk | LEC Superseded by part number: 140021 |
| 8. | 16162437 | [6] | BOLT,Hex, M18 x 2.5 x 45mm, Cl 10.9, Full Thd | LECSCREW 18x2,5x45 |
| 9. | 14497031 | [6] | WASHER,M18 x 34 | LEC |
| 10. | 8294271 | [1] | CUTTING EDGE | LEC Superseded by part number: 73117701 |
| 11. | 8282270 | [20] | PLOW BOLT,Plow, M20 x 1.5 x 67mm, Cl 10.9 | LEC |
| 12. | 79077486 | [2] | CUTTING EDGE | LEC |
