凯斯零件查询(8570) - CASE IH MID-SIZE RECTANGULAR BALER (1/91-12/96) (6-32) - LUBE ASSEMBLY, CENTRALIZED Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
424 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700000244
|
[2] |
ELBOW
|
CAS
1/8-27 X 45 DEGREE STREET ELL Superseded by part number: 217-1084
|
| 2. |
700706798
|
[2] |
FLEXIBLE HOSE
|
CAS
HOSE ASSEMBLY Superseded by part number: 84474184
|
| 3. |
703603
|
[2] |
SCREW
|
CAS
3/8-16 X 1-1/2 C
|
| 4. |
704734
|
[21] |
FLANGE NUT,Flg, 3/8"-16
|
IH
3/8-16 HFTLN GRG Superseded by part number: 86521609
|
| 5. |
700113671
|
[2] |
CLAMP
|
CAS
- LINE
|
| 6. |
7883382
|
[19] |
BOLT,Hex, 3/8" - 16 x 1", Gr 120M
|
CAS
3/8-16 X 1 HWHMS Superseded by part number: 87034804
|
| 7. |
751487
|
[9] |
CLAMP
|
CAS
1/2 ID CLAMP Superseded by part number: 86632595
|
| 8. |
700706840
|
[2] |
HYD CONNECTOR
|
CAS
CONNECTOR - FEMALE
|
| 9. |
700706842
|
[2] |
ELBOW
|
CAS
90 DEGREE ELBOW - MALE Superseded by part number: 86512947
|
| 10. |
700123990
|
[1] |
HARNESS
|
CAS
- LUBE, PICKUP
|
| 11. |
700706682
|
[9] |
FRONT AXLE
|
CAS
1/8-27 X 90 DEGREE ELBOW Superseded by part number: 30773V, 222-1845
|
| 12. |
700706683
|
[5] |
HYD CONNECTOR
|
CAS
CONNECTOR - MALE Superseded by part number: 219-300
|
| 13. |
700706679
|
[16] |
FERRULE
|
CAS
SLEEVE - BALL Superseded by part number: 30774V
|
| 14. |
705525
|
[1] |
WASHER
|
CAS
5/16 HARDENED PLAIN WASHER Superseded by part number: 86637953
|
| 15. |
700707011
|
[1] |
HOLDER
|
CAS
- GREASE GUN
|
| 16. |
7701444
|
[4] |
SCREW
|
CAS
10-32 X 1-3/4 HWHMS
|
| 17. |
751628
|
[8] |
CLAMP
|
CAS
1/4 ID CLAMP Superseded by part number: 675162
|
| 18. |
86624005
|
[3] |
CLAMP,19mm, Coat, 10.3mm Bolt Hole, P Type
|
FOR
3/4 ID CLAMP
|
| 19. |
700123987
|
[1] |
HARNESS
|
CAS
- LUBE, FRONT
|
| 20. |
704445
|
[4] |
NUT
|
CAS
10-32 H Superseded by part number: 87825
|
| 21. |
700123988
|
[1] |
HARNESS
|
CAS
- LUBE, LEFT
|
| 22. |
827238
|
[1] |
GROMMET,5/8" ID x 1 1/4" Groove Dia, Str Cut
|
CAS
Superseded by part number: 86637780
|
| 23. |
214-1412
|
[5] |
HOSE CLAMP,#12, 0.69" - 1.25", Type F Worm
|
CAS
CLAMP - HOSE Superseded by part number: 87779385, 86625021
|
| 24. |
7827561
|
[1] |
GROMMET
|
CAS
Superseded by part number: 248-13101
|
| 25. |
77115
|
[2] |
FITTING
|
CAS
1/8-27 X 90 DEGREE ZERK Superseded by part number: 80717
|
| 26. |
700706684
|
[16] |
HYD CONNECTOR
|
CAS
NUT - COMPRESSION
|
| 27. |
700706678
|
[16] |
FERRULE
|
CAS
|
| 28. |
700123989
|
[1] |
HARNESS
|
CAS
- LUBE, REAR
|
| 29. |
700706837
|
[2] |
MANIFOLD
|
CAS
VALVE BLOCK - LUBE
|
