纽荷兰零件查询(FD14E) - CRAWLER DOZER (94.5551[001]) - SWINGING DRAWBAR New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
689 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 15629 | [2] | PIN,24mm OD x 131mm L | MOD |
| 2. | 5112606 | [2] | COTTER PIN | TTF |
| 3. | 4955443 | [1] | BRACKET | LEC- RIGHT |
| 3. | 4955449 | [1] | BRACKET | LEC- LEFT |
| 4. | 4955452 | [2] | PLATE | LEC |
| 5. | 4955451 | [1] | SWINGING DRAWBAR | LECCROSS BEAM |
| 6. | 4955502 | [1] | CHAIN | BHB |
| 7. | 4955552 | [1] | SUPPORT | LEC |
| 8. | 4955553 | [1] | PIN | LEC |
| 9. | 4977809 | [1] | PIN | LEC |
| 10. | 4977813 | [1] | BUSHING | LEC |
| 11. | 4977820 | [1] | DRAWBAR | LEC- ASSEMBLY |
| 12. | 8268534 | [1] | ROLL PIN,7mm OD | LECSPRING PIN |
| 13. | 10517679 | [18] | LOCK WASHER,24.3mm ID x 38.3mm OD x 5.5mm Thk | BHBLOCKWASHER 24,3x5,5 Superseded by part number: 86509829 |
| 14. | 11398134 | [8] | BOLT,Hex, M24 x 2 x 80mm, Cl 10.9 | LECSCREW 24x2x80 |
| 15. | 12164521 | [4] | NUT,Hex, M24, 2mm Pitch,19mm High, Cl 10 | MOD24x2x19 Superseded by part number: 12164527 |
| 16. | 14173370 | [1] | ROLL PIN | MKTSPRING PIN 10,5x70 Superseded by part number: 14610770 |
| 17. | 15997134 | [6] | SCREW | LEC24x2x60 Superseded by part number: 15997137 |
| 18. | 15997734 | [4] | BOLT,Hex, M24 x 2 x 110mm, Cl 10.9 | LECSCREW 24x2x110 Superseded by part number: 15997737 |
