凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (9-12) - BALE ROLLER CHUTE KIT, HK40831 BALE ROLLER CHUTE KIT COMPLETE, INCLUDES PAGES 9-12 THRU 9-15 Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (9-12) - BALE ROLLER CHUTE KIT, HK40831 BALE ROLLER CHUTE KIT COMPLETE, INCLUDES PAGES 9-12 THRU 9-15 Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 613 次

Pos.	Part No	Qty	Parts name	Comments
. .	HK40831	[1]	CHUTE (DOWNWARD)	ATT BALE ROLLER CHUTE KIT COMPLETE (Includes Figures: 9-12 Thru 9-15)
1.	433-816	[2]	CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5	CAS 1/2-13 X 1 RHSNB Superseded by part number: 280486
2.	231-5348	[10]	FLANGE NUT,Flg, 1/2"-13	CAS 1/2-13 HFTLN GR/G Superseded by part number: 86521610
3.	700129744	[1]	ANGLE	CAS WA-LEFT
4.	413-1016	[4]	BOLT,Hex, 5/8" - 11 x 1", Gr 5	CAS 5/8-11 X 1 C Superseded by part number: 280580
5.	492-11062	[4]	BEARING WASHER,5/8"	CAS WASHER, LOCK, 5/8" Superseded by part number: 86729275
6.	111-360	[20]	CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5	CAS BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
7.	232-5316	[24]	FLANGE NUT,Flg, 3/8"-16	CAS 3/8-16 HFTLN GR/G Superseded by part number: 86521609
8.	700108622	[8]	FLANGED BEARING	L FLANGE
9.	710392	[8]	BEARING, ROLLER, CYL,27.33 mm ID x 47.09 mm OD x 25.4 mm	L BEARING-CYLINDRICAL Superseded by part number: 84330047
10.	38-11624	[8]	LOCK PIN,1/4" x 1 1/2", Slotted	CAS PIN, 1/4" x 1 1/2", Slotted Superseded by part number: 87406
11.	121-115	[4]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
12.	232-5315	[4]	FLANGE NUT,Flg, 5/16"-18	CAS 5/16-18 HFTLN GR/G
13.	700129724	[1]	CHANNEL	CAS WA-LEFT Superseded by part number: 700139258
14.	121-425	[8]	FLANGE BOLT,Hex, 1/2" - 13 x 1", Gr 8	CAS 1/2-13 X 1 HFS GR8 Superseded by part number: 87034823
15.	700129717	[1]	SUPPORT	CAS WA
16.	700129756	[1]	CHANNEL	CAS WA-RIGHT Superseded by part number: 700139259
17.	700129745	[1]	ANGLE	CAS WA-RIGHT
18.	581469R1	[4]	FLANGE,Bearing	IH
19.	455959R92	[2]	BEARING ASSY,28.57mm ID x 62mm OD x 18mm W	CAS -SPHERICAL Superseded by part number: 47577195
20.	700129737	[1]	SHIELD	CAS
21.	700129736	[1]	SHIELD	CAS
22.	700129714	[4]	TUBE,816 mm Length	CAS WA-FRONT
23.	700129728	[1]	SUPPORT	CAS WA
24.	700129710	[1]	TUBE,816 mm Length	CAS WA-REAR
25.	700129739	[1]	CHANNEL	CAS -REAR
26.	434-616	[4]	CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5	CAS 3/8-16 X 1 RHSNB Superseded by part number: 80280503
