凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (2-04) - DRIVE LINE AND MOUNTING ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
128 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
413-820
|
[7] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
80679
|
[11] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 3. |
700123820
|
[1] |
SHAFT
|
CAS
|
| 4. |
413-1048
|
[1] |
BOLT,Hex, 5/8" - 11 x 3", Gr 5
|
CAS
Superseded by part number: 87338
|
| 5. |
232-41110
|
[1] |
NUT,5/8"-11, GC
|
CAS
NUT, LOCK, 5/8"-11, GC Superseded by part number: 85700693
|
| 6. |
668719R92
|
[1] |
BEARING ASSY,1.7505" ID x 3.346" OD x 1.1875" Thk
|
IH
BEARING - SPHERICAL Superseded by part number: 668718R92
|
| 7. |
700113022
|
[1] |
SUPPORT
|
CAS
|
| 8. |
700124004
|
[1] |
BEARING ASSY,44.45 mm ID x 85 mm OD x 29 mm
|
CAS
BEARING ASSEMBLY (Includes Ref: 6)
|
| 9. |
425-108
|
[8] |
NUT,1/2" - 13, Gr 5
|
CAS
NUT, , Hex 1/2"-13, G5 Superseded by part number: 280431
|
| 10. |
433-820
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1 1/4", Gr 5
|
CAS
1/2-13 X 1-1/4 RHSNB Superseded by part number: 87868
|
