| 1. |
47530
|
[1] |
LINK, CONNECTING
|
IH
LINK-CONNECTOR, #50 R/C
|
| 2. |
1791D
|
[1] |
CHAIN (AG),#50, 192 Links x 15.88mm = 3048mm
|
IH
CHAIN-ROLLER, #50 (10 FOOT BULK)
|
| 3. |
86439
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA-50B20 TOOTH
|
| 4. |
Q3929
|
[1] |
KEY,Gib, 5/16" Sq x 1 1/2"
|
IH
5/16 X 1-1/2 GIB KEY
|
| 5. |
700123773
|
[1] |
SPROCKET ASSY.
|
CAS
SPROCKET WA-50B30 TOOTH
|
| 6. |
T27207
|
[4] |
FLANGED BEARING
|
CAS
FLANGE-BEARING Superseded by part number: 617863R1
|
| 7. |
571588R92
|
[1] |
BALL BEARING,1.3755" ID x 72 mm OD x 1"
|
IH
-SPHERICAL Superseded by part number: 47066
|
| 8. |
111-360
|
[3] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 9. |
492-11038
|
[6] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 10. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 11. |
700129658
|
[27] |
TINE BAR
|
CAS
WRAPPER Superseded by part number: 84468627
|
| 12. |
409-7512
|
[54] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 13. |
700133123
|
[1] |
SENDER UNIT
|
HFI
PICKUP WA (Includes Ref: 22)
|
| 14. |
700123764
|
[1] |
AUGER
|
CAS
WA-LEFT
|
| 15. |
434-616
|
[3] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 16. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 17. |
565672R92
|
[1] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING-SPHERICAL Superseded by part number: 84330041
|
| 18. |
433-1056
|
[2] |
CARRIAGE BOLT,Sq Nk, 5/8" - 11 x 3 1/2", Gr 5
|
CAS
5/8-11 X 3-1/2 RHSNB Superseded by part number: 280563
|
| 19. |
492-11062
|
[2] |
BEARING WASHER,5/8"
|
CAS
WASHER, LOCK, 5/8" Superseded by part number: 86729275
|
| 20. |
425-1010
|
[2] |
NUT,5/8"-11, G5
|
CAS
Superseded by part number: 280374
|
| 21. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
1/8-27 STRAIGHT ZERK-SPECIAL Superseded by part number: 80710
|
| 22. |
6186506
|
[1] |
BUSHING,38.2mm ID x 44.58mm OD x 50.8mm L
|
CAS
-BRONZE
|
| 23. |
121-115
|
[4] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 24. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 25. |
700133129
|
[2] |
SUPPORT
|
CAS
-LATCH
|
| 26. |
52175
|
[3] |
BUSHING,25.48mm ID x 38.2mm OD x 3.17mm L
|
CAS
5/8 X 18 GAUGE NRMB
|
| 27. |
6176655
|
[2] |
BUSHING
|
CAS
SPACER
|
| 28. |
Q3914
|
[1] |
KEY,Gib, 1/4" Sq x 1 1/2"
|
IH
1/4 X 1-1/2 GIB KEY
|
| 29. |
211623C91
|
[2] |
SPROCKET
|
IH
-IDLER, 17 TOOTH
|
