| 1. |
434-616
|
[4] |
CARRIAGE BOLT,Sht Sq Nk, 3/8" - 16 x 1", Gr 5
|
CAS
3/8-16 X 1 RHSNB Superseded by part number: 80280503
|
| 2. |
492-11038
|
[4] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 3. |
425-106
|
[4] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 4. |
700123808
|
[1] |
PIVOT
|
CAS
WA-CYLINDER
|
| 5. |
700113281
|
[1] |
SPACER
|
CAS
|
| 6. |
413-1248
|
[1] |
BOLT,Hex, 3/4" - 10 x 3", Gr 5
|
CAS
.75 X 3 UNC GR5 YZD Superseded by part number: 87337
|
| 7. |
230-41112
|
[1] |
LOCK NUT,3/4"-10, GA
|
CAS
3/4-10 HTLN GR/B Superseded by part number: 280375
|
| 8. |
121-115
|
[8] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 9. |
231-5145
|
[12] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 10. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 11. |
700123789
|
[1] |
PANEL
|
HFI
SHIELD-RIGHT Superseded by part number: 700133183
|
| 12. |
409-7512
|
[6] |
BOLT,Hex Flg, 5/16" - 18 x 3/4", Spcl
|
CAS
Hex Flg, 5/16-18 x 3/4", Serr Superseded by part number: 145913, 72187186
|
| 13. |
565672R92
|
[1] |
SPHERICAL BEARING,1.2505" ID x 72 mm OD x 1"
|
IH
BEARING-SPHERICAL Superseded by part number: 84330041
|
| 14. |
T27207
|
[2] |
FLANGED BEARING
|
CAS
FLANGE Superseded by part number: 617863R1
|
| 15. |
700108658
|
[2] |
SUPPORT
|
CAS
-HINGE Superseded by part number: 700163299
|
| 16. |
413-58
|
[4] |
BOLT,Hex, 5/16" - 18 x 1/2", Gr 5
|
CAS
5/16-18 X 1/2 C Superseded by part number: 72187203, 88574
|
| 17. |
6844344
|
[1] |
PIN
|
CAS
-HINGE
|
| 18. |
700133121
|
[1] |
SHIELD
|
CAS
-RIGHT Superseded by part number: 700162029
|
| 19. |
700714528
|
[1] |
LATCH
|
CAS
-1/4 TURN (Includes Nut) Superseded by part number: 292505A1
|
| 20. |
76695
|
[6] |
WASHER
|
CAS
FENDER-WASHER
|
| 21. |
700708648
|
[2] |
BUMPER
|
CAS
|
| 22. |
1954816C1
|
[2] |
LOCK NUT
|
IH
#12-24 HCLN SPL Superseded by part number: 848083
|
| 23. |
700707203
|
[2] |
CAPTIVE WASHER SCREW
|
CAS
#12-24 X 3/4 HWHMS
|
| 24. |
700123849
|
[1] |
SHIELD
|
CAS
|
| 25. |
700133119
|
[1] |
SHIELD
|
HFI
-PICKUP, RIGHT
|
| 26. |
121-133
|
[3] |
SERRATED BOLT,Hex, 5/16" - 18 x 5/8", Gr 5
|
CAS
Superseded by part number: 271288
|
| 27. |
340-1108
|
[4] |
SCREW,Cross Pan Hd, #10-24 x 1/2"
|
CAS
#10-24 X 1/2 CRPHMS GR2
|
| 28. |
195-513
|
[4] |
WASHER,#10
|
CAS
PLAIN WASHER #10 Superseded by part number: 9824326
|
| 29. |
492-11010
|
[4] |
LOCK WASHER,#10
|
CAS
WASHER, LOCK, #10 Superseded by part number: 80684
|
| 30. |
225-14110
|
[4] |
NUT,#10-24
|
CAS
Superseded by part number: 87304
|
| 31. |
700714529
|
[1] |
SOCKET/RECEPTACLE
|
CAS
RECEPTACLE Superseded by part number: 292504A1
|
| 32. |
700123807
|
[1] |
SUPPORT
|
CAS
|
