纽荷兰零件查询(FD14E) - CRAWLER DOZER (95.6560[002]) - HEATER-PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
771 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79079723 | [1] | HOSE | LEC Superseded by part number: 78100219 |
| 2. | 79079724 | [1] | FLEXIBLE HOSE | LECHOSE Superseded by part number: 78100219 |
| 3. | 79044181 | [2] | HYD CONNECTOR | LECFITTING C2672 |
| 4. | 79044183 | [2] | HYD CONNECTOR | LECFITTING Superseded by part number: 76033090 |
| 5. | 79028876 | [2] | SEAL,21.5mm ID x 28.7mm OD x 2.5mm Thk | LEC |
| 6. | 10182614 | [2] | BANJO BOLT,M20 x 1.5 x 36mm | JESFITTING C2672 |
| 7. | 79083842 | [4] | HOSE CLAMP,M16-27 | LECCLAMP, HOSE, M16-27 Superseded by part number: 18088392 |
| 8. | 79044182 | [2] | DRAINCOCK/TAP SUPPLY | LECCOCK |
| 9. | 10450790 | [2] | RETAINER COLLAR,22mm, Coat, 9mm Bolt Hole, P Type | LECCLIP 22x9 Superseded by part number: 10450990 |
| 10. | 16043431 | [1] | SCREW,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | BHB Superseded by part number: 16605534 |
| 11. | 16100821 | [1] | NUT,M8, Cl 10 | LEC Superseded by part number: 43362 |
| 12. | 14496531 | [1] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC8.15x17 Superseded by part number: 86624184 |
| 13. | 79098222 | [2] | HYD CONNECTOR | LECFITTING - ASSEMBLY D2672 |
| 14. | 78100251 | [1] | O-RING,17.86mm ID x 2.62mm Width | LEC0-RING D2672 |
| 15. | 79054406 | [2] | HYD CONNECTOR | LECFITTING D2672 |
