神钢零件查询(F4HFE613E B005) - ENGINE 5801925171 47748445 CX5090 S/L/H T4B (1/12-) (10.414.AE) - BELT TENSIONER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
782 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 2856946 | [1] | BELT TENSIONER | TORFan Drive Superseded by part number: |
| 2. | 2852398 | [1] | IDLER WHEEL,65mm OD | TORPulley Superseded by part number: 504065877 |
| 3. | NS | [1] | NOT SERVICED | BASSupport |
| 5. | 2854424 | [1] | SCREW,Hex, Flg Hd, M10 x 1.5 x 70mm | TOR Superseded by part number: 16676834 |
| 6. | NS | [1] | NOT SERVICED | BASBelt |
| 7. | 2852397 | [1] | IDLER,65mm OD | TOR Superseded by part number: 504065878 |
