纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (0.140[06]) - INJECTION EQUIPMENT - INJECTION PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
540 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 9969138 | [1] | BODY | LEC- ASSY |
| 2. | 75204112 | [1] | PLUG | ZED Superseded by part number: 9978003 |
| 3. | 772353 | [1] | ROLL PIN | BRE |
| 4. | 774244 | [1] | RING NUT | BRE Superseded by part number: 42493099 |
| 5. | 772354 | [2] | BUSHING | BRE Superseded by part number: 9929611 |
| 6. | 79038472 | [1] | GASKET | LEC14X20 Superseded by part number: 691273C1 |
| 7. | 76026109 | [1] | HYDRAULIC VALVE | LEC |
| 8. | 74060325 | [7] | GASKET | MKT Superseded by part number: 79038381 |
| 9. | 9966715 | [1] | WASHER | BRE |
| 10. | 79102504 | [1] | SEAL | MOD Superseded by part number: 6917220 |
| 11. | 9918542 | [1] | PLUG | LEC |
| 12. | 15896211 | [3] | NUT,M6, Cl 8 | JES Superseded by part number: 17037821 |
| 13. | 76026116 | [1] | SEAL | LEC Superseded by part number: 6917220 |
| 14. | 10571574 | [3] | LOCK WASHER | LEC6,1X1,6 Superseded by part number: 17798174 |
| 15. | 79062792 | [12] | SCREW | LEC |
| 16. | 76026115 | [1] | SEAL | LEC |
| 17. | 76026114 | [1] | COVER | LEC |
| 18. | 15896421 | [12] | NUT,M5, Cl 10 | TTF Superseded by part number: 1112803 |
| 19. | 772334 | [6] | PLUG | BRE Superseded by part number: 769765 |
| 20. | 79038380 | [12] | WASHER | LEC Superseded by part number: 773325 |
| 22. | 9969145 | [1] | PLUG | LEC |
| 23. | 11500211 | [3] | STUD | MKT |
| 24. | 79038464 | [1] | O-RING | LEC55X2 |
| 25. | 768349 | [1] | COVER PLATE | LEC- THICKNESS 0,30 |
| 25. | 768350 | [1] | COVER PLATE | LEC- THICKNESS 0,50 |
| 25. | 772287 | [1] | SHIM | BRE- THICKNESS 0,16 Superseded by part number: 9929644 |
| 25. | 772288 | [1] | SHIM | BRE- THICKNESS 0,18 Superseded by part number: 9929645 |
| 25. | 9929641 | [1] | SHIM,0.10mm Thk | LEC |
| 25. | 9929642 | [1] | SHIM,0.12mm Thk | LEC |
| 25. | 79038559 | [1] | SHIM | NH- THICKNESS 0,14 Superseded by part number: 79038459 |
| 26. | 9969144 | [1] | COVER | LEC |
| 27. | 76031625 | [12] | STUD | LEC |
| 28. | 76026110 | [4] | SCREW | LEC- IN ALTERNATIVE |
| 28. | 9968622 | [4] | SCREW | BRE- IN ALTERNATIVE Superseded by part number: 76026110 |
| 29. | 9929727 | [1] | PLUG | LEC |
| 30. | 9957969 | [1] | SPACER | MOD |
| 31. | 1308047 | [1] | KIT | LEC |
