| 1. |
413-624
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/2", Gr 5
|
CAS
Superseded by part number: 72187209, 88044
|
| 2. |
496-11041
|
[6] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
3/8 HARDENED PLAIN WASHER Superseded by part number: 86632588
|
| 3. |
492-11038
|
[3] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 4. |
425-106
|
[6] |
NUT,3/8"-16, Cl 5
|
CAS
Superseded by part number: 9628503
|
| 5. |
700123429
|
[1] |
ARM
|
CAS
-TRIP
|
| 6. |
61978
|
[1] |
KEY
|
CAS
1/4 X 2-1/2 GIB KEY
|
| 7. |
6524946
|
[1] |
WIPER ARM
|
CAS
ARM-DOOR
|
| 8. |
111-361
|
[2] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 1 1/2", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/2", G5 Superseded by part number: 9706752
|
| 9. |
231-4116
|
[2] |
NUT,3/8"-16, GB
|
CAS
3/8-16 HTLN Superseded by part number: 88902, E64197
|
| 10. |
858308
|
[1] |
SPRING
|
CAS
-TENSION
|
| 11. |
766485
|
[1] |
EYEBOLT,3/8" - 16 x 5", Full Thd
|
CAS
DRAW BOLT
|
| 12. |
433-620
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 1 1/4", G5 Superseded by part number: 86508773
|
| 13. |
432-1632
|
[1] |
COTTER PIN,1/4" x 2"
|
CAS
Pin, Split (Cotter), 1/4" x 2" Superseded by part number: 88182
|
| 14. |
700123432
|
[1] |
STOP
|
CAS
-ARM
|
| 15. |
700112815
|
[2] |
SUPPORT
|
CAS
|
| 16. |
N5077
|
[2] |
FLANGED BEARING
|
CAS
BEARING
|
| 17. |
113-242
|
[1] |
BOLT
|
CAS
3/8-16 X 1-1/4 FTC Superseded by part number: 88011
|
| 18. |
219-1
|
[1] |
LUBE NIPPLE,1/8" - 27 NPTF
|
CAS
1/8-27 ZERK Superseded by part number: 80710
|
| 19. |
495-81070
|
[4] |
WASHER,1 1/32" x 1 1/2" x .120"
|
CAS
1 X 10 NRMB Superseded by part number: 86624170
|
| 20. |
433-512
|
[6] |
CARRIAGE BOLT,Sq Nk, 5/16" - 18 x 3/4", Gr 5
|
CAS
Superseded by part number: 280327
|
| 21. |
231-5145
|
[6] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
NUT, Flg, USR, 5/16"-18 Superseded by part number: 72187067, 145458
|
| 22. |
111-360
|
[8] |
CARRIAGE BOLT,Short NK, 3/8"-16 x 3/4", G5
|
CAS
BOLT, CARRIAGE, Short NK, 3/8"-16 x 3/4", G5 Superseded by part number: 280430
|
| 23. |
231-5146
|
[8] |
FLANGE NUT,3/8"-16
|
CAS
Superseded by part number: 72187068, 247780
|
| 24. |
700123425
|
[1] |
DOOR
|
CAS
Superseded by part number: 700153076
|
| 25. |
100-1175
|
[2] |
SNAP RING,#75, Ext
|
CAS
Ring, Snap, #75, Ext Superseded by part number: 72186587, 129164
|
| 26. |
6524870
|
[1] |
ROLLER,41.28mm OD x 19mm L
|
CAS
-CAM
|
| 27. |
700123435
|
[1] |
STOP
|
CAS
ARM-CAM
|
| 28. |
6525042
|
[1] |
ROLLER,41.28mm OD x 12.5mm L
|
CAS
-CAM
|
| 29. |
CAS51383
|
[1] |
END
|
CAS
BEARING-ROD END
|
| 30. |
700123439
|
[1] |
ROD
|
CAS
|
| 31. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Ring, Snap, #100, Ext Superseded by part number: 25121
|
| 32. |
129-323
|
[1] |
SPECIAL NUT,3/8"-24, G5, LH
|
CAS
|
| 33. |
425-116
|
[1] |
NUT,3/8" - 24, Gr 5
|
CAS
Superseded by part number: 86509310, 50066
|
| 34. |
700705523
|
[1] |
SPHERICAL BEARING,9.52 mm ID x 12.7 mm
|
CAS
BRG-ROD END (LH THREAD)
|
| 35. |
6179832
|
[1] |
SPACER
|
CAS
|
