凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (EUROPE) (1/95-12/00) (6-10) - KNOTTER HEAD ASSEMBLY, (CON'T) Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
985 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
19877R1
|
[1] |
DOWEL
|
IH
3/16 X 1/2 DOWEL PIN Superseded by part number: 88251
|
| 2. |
1712835
|
[1] |
HOOK
|
CAS
BILL HOOK ASSEMBLY Superseded by part number: 700734488
|
| 3. |
163-47
|
[2] |
SCREW,Hex, #10 - 32 x 1/2", Gr 5
|
CAS
Superseded by part number: 86637658
|
| 4. |
6613624
|
[1] |
WASHER, LOCK
|
CAS
TAB-LOCKING
|
| 5. |
700715627
|
[1] |
KNIFE
|
CAS
-TWINE Superseded by part number: 700718710
|
| 6. |
700102136
|
[1] |
KNIFE
|
CAS
BASE-KNIFE, TWINE
|
| 7. |
495-11053
|
[1] |
WASHER,1/2", SAE
|
CAS
(17/32" x 1-1/16" x 3/32") 1/2", SAE Superseded by part number: 87364, 72187259
|
| 8. |
80679
|
[1] |
LOCK WASHER,1/20.507 CST ZND
|
NH
WASHER, LOCK, 1/2"
|
| 9. |
425-118
|
[1] |
NUT,1/2"-20, G5
|
CAS
1/2-20 H Superseded by part number: 280963
|
| 10. |
7852593
|
[2] |
SHIM,15mm ID x 21mm OD x 1mm Thk
|
CAS
9/16 X 20 GA. MACHINERY BUSHING Superseded by part number: 84007145
|
| 11. |
700122799
|
[1] |
ROLLER
|
CAS
-SPHERICAL
|
| 12. |
7852577
|
[1] |
RING, SNAP
|
CAS
RING-RETAINING
|
| 13. |
6591580
|
[1] |
SHAFT
|
CAS
-TWINE (Includes Ref: 15)
|
| 14. |
238-5016
|
[1] |
O-RING,0.07" Thk x 0.614" ID, -16, Cl 5, 75 Duro
|
CAS
-016, 70 Duro, .614" ID x .070" Thk Superseded by part number: 128359
|
