凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (09-014) - SLOT CLEANER KIT, 700129421 SLOT CLEANER KIT COMPLETE, S.N. CFH0113001 THRU CFH0117523 Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
644 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700129422
|
[1] |
CLEANER
|
CAS
WA, Includes: Ref. 11
|
| 2. |
6232946
|
[4] |
BUSHING
|
CAS
Superseded by part number: 706232946
|
| 3. |
700122588
|
[2] |
ANGLE
|
CAS
angle
|
| 4. |
433-612
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 280430
|
| 5. |
232-5316
|
[8] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 6. |
433-620
|
[4] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 1/4", Gr 5
|
CAS
Superseded by part number: 86508773
|
| 7. |
495-21044
|
[6] |
WASHER,3/8"
|
CAS
Superseded by part number: 87779090, 80702
|
| 8. |
700129431
|
[2] |
STRAP
|
CAS
|
| 9. |
433-628
|
[2] |
CARRIAGE BOLT,Sq Nk, 3/8" - 16 x 1 3/4", Gr 5
|
CAS
3/8-16 x 13/4 RHSNB Superseded by part number: 86508775
|
| 10. |
6518302
|
[2] |
SPACER
|
CAS
bushing
|
| 11. |
740787
|
[2] |
BRONZE BUSHING
|
CAS
|
