| 1. |
700715339
|
[1] |
HOSE
|
CAS
hydraulic
|
| 3. |
496-11028
|
[1] |
WASHER,9/32" x 5/8" x .065, HDN
|
CAS
hardened plain, 1/4 Superseded by part number: 86632587
|
| 4. |
1703354
|
[1] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 5. |
700706340
|
[2] |
MAGNET
|
CAS
|
| 6. |
438-11620
|
[1] |
LOCK PIN,1/4" x 1 1/4", Slotted
|
CAS
1/4" x 1 1/4", Slotted
|
| 7. |
751321
|
[2] |
CLAMP
|
CAS
line Superseded by part number: 80272535
|
| 8. |
700129596
|
[1] |
SHAFT
|
CAS
WA
|
| 9. |
413-612
|
[1] |
BOLT,Hex, 3/8" - 16 x 3/4", Gr 5
|
CAS
Superseded by part number: 72187204, 86500692
|
| 10. |
492-11038
|
[1] |
LOCK WASHER,3/8"
|
CAS
Superseded by part number: 80680, 72187249
|
| 11. |
496-81010
|
[1] |
WASHER
|
CAS
hardened wide plain, 3/8 Superseded by part number: 86625244
|
| 12. |
237-6008
|
[1] |
O-RING,0.087" Thk x 0.644" ID, -908, Cl 6, 90 Duro
|
CAS
Superseded by part number: 128825
|
| 13. |
218-5106
|
[4] |
90 ELBOW,90 Degree Elbow, 3/4" - 16 Male JIC x 3/4" - 16 Male ORB
|
CAS
Includes: Ref. 12 Superseded by part number: 72186176, 128830
|
| 14. |
218-5059
|
[2] |
HYD CONNECTOR,3/4"-16, 37 Degree x 3/4"-16, O-Ring
|
CAS
Straight, Male, Incl. Ref 12 Superseded by part number: 128818
|
| 15. |
515-23190
|
[3] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86624005
|
| 16. |
7702012
|
[1] |
SELF-TAP SCREW,3/8" - 16 x 1"
|
CAS
3/16-16 x 1 HWHTCTS
|
| 17. |
700715340
|
[1] |
HOSE
|
CAS
hydraulic
|
| 18. |
700715216
|
[1] |
VALVE
|
CAS
ASSEMBLY, Includes: Ref. 42
|
| 19. |
413-636
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/4", Gr 5
|
CAS
Superseded by part number: 88546, 72187212
|
| 20. |
232-5316
|
[5] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
| 21. |
413-616
|
[2] |
BOLT,Hex, 3/8" - 16 x 1", Gr 5
|
CAS
Superseded by part number: 88206, 72187206
|
| 22. |
496-11041
|
[3] |
WASHER,13/32" x 13/16" x .065", HDN
|
CAS
hardened plain, 3/8 Superseded by part number: 86632588
|
| 23. |
700715291
|
[1] |
DECAL
|
CAS
operational
|
| 24. |
100-11100
|
[1] |
SNAP RING,#100, Ext
|
CAS
Superseded by part number: 25121
|
| 25. |
195-2103
|
[1] |
WASHER,1 1/16" x 1 1/2" x .065"
|
CAS
1 x 18 gauge NRMB
|
| 26. |
515-2363
|
[2] |
CLAMP,M6.3, Insul, 3/8" Bolt
|
CAS
line Superseded by part number: 675162
|
| 27. |
700107977
|
[1] |
GUIDE
|
CAS
twine
|
| 28. |
700129475
|
[1] |
ANGLE
|
CAS
BRACKET
|
| 30. |
700129474
|
[1] |
ANGLE
|
CAS
SHIELD
|
| 31. |
700113863
|
[2] |
SENSOR
|
CAS
ASSEMBLY
|
| 32. |
434-412
|
[2] |
CARRIAGE BOLT,Sht Sq Nk, 1/4" - 20 x 3/4", Gr 5
|
CAS
1/4-20 x 3/4 RHSNB Superseded by part number: 280638
|
| 2. |
413-420
|
[1] |
BOLT,Hex, 1/4" - 20 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87716, 72187191
|
| 34. |
492-11025
|
[3] |
LOCK WASHER,1/4"
|
CAS
Superseded by part number: 72187247, 80682
|
| 35. |
425-104
|
[3] |
NUT,1/4"-20, Cl 5
|
CAS
Superseded by part number: 7770, 72187220
|
| 36. |
700129477
|
[2] |
CHANNEL
|
CAS
mounting
|
| 37. |
51200165
|
[1] |
SCREW,Hex, 1/4"-20 x 1", G5
|
HFI
1/4-20 x 1 C
|
| 38. |
700711751
|
[1] |
CLAMP
|
CAS
line
|
| 39. |
L18337
|
[1] |
CABLE TIE,9.95"-12.1" lg
|
CAS
CABLE STRAP TIE nylon Superseded by part number: 529070
|
| 40. |
700715223
|
[1] |
HARNESS
|
CAS
wiring
|
| 41. |
413-620
|
[1] |
BOLT,Hex, 3/8" - 16 x 1-1/4", Gr 5
|
CAS
C Superseded by part number: 72187207, 88011
|
| 42. |
700716436
|
[1] |
KNOB
|
CAS
|
