凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (09-032) - KNOTTER BLOWER KIT, HK40953 COMPLETE, INCLUDES PGS 9-32 THRU 9-43 TO BE ORDERED THRU WHOLEGOODS ONLY Case Agriculture_凯斯Case_工程机械

凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (09-032) - KNOTTER BLOWER KIT, HK40953 COMPLETE, INCLUDES PGS 9-32 THRU 9-43 TO BE ORDERED THRU WHOLEGOODS ONLY Case Agriculture

广数供应链运营团队, 15 02月, 2025，浏览： 307 次

Pos.	Part No	Qty	Parts name	Comments
1.	515-23254	[4]	CLAMP,1", Insul, 3/8" Bolt	CAS Line Superseded by part number: 9827902, 72187281
2.	515-23190	[4]	CLAMP,3/4", Insul, 3/8" Bolt	CAS Line Superseded by part number: 86624005
3.	6553804	[2]	SPACER	HFI
4.	113-250	[2]	BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd	CAS
5.	329-286	[4]	FLANGE NUT,Flg, 3/8"-16, G8	CAS
6.	873018	[4]	BOLT,5/16" - 18 x 3 3/4", Gr 5	HFI 5/16-18 x 3-3/4 C
7.	495-61034	[4]	WASHER,0.34" ID x 0.88" OD x 0.06" Thk	CAS wide plain, 5/16
8.	231-5145	[4]	SERRATED NUT,Flg, USR, 5/16"-18	CAS Superseded by part number: 72187067, 145458
9.	700133097	[2]	SUPPORT	HFI SHIELD
10.	700150595	[1]	SHIELD	HFI flywheel
11.	700150596	[2]	STRAP	HFI SUPPORT, SHIELD
12.	121-115	[7]	SERRATED BOLT,Hex, 5/16" - 18 x 3/4"	CAS
13.	700150591	[6]	CHANNEL	HFI mounting
14.	700150597	[1]	STRAP	HFI CABLE, support
15.	121-237	[2]	SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl	CAS 3/8-16 x 1-1/4 HFS GR8 Superseded by part number: 87327172
16.	700717865	[1]	HOSE	CAS hydraulic
17.	700718207	[1]	HOSE	CAS hydraulic
18.	218-5123	[1]	ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB	CAS 90 Deg., hydraulic Superseded by part number: 144123
19.	700150589	[1]	SUPPORT	HFI blower
20.	121-108	[9]	BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr	CAS 5/16-18 x 1 HWHMS
21.	496-21034	[3]	WASHER,11/32" x 11/16" x 0.89", HDN	CAS Superseded by part number: 86637953
22.	232-5315	[10]	FLANGE NUT,Flg, 5/16"-18	CAS 5/16-18 HFTLN GR/G
23.	700149723	[1]	STRAP	HFI support
24.	700701753	[1]	HYD CONNECTOR	CAS hydraulic, Includes: Ref. 25
25.	738484	[1]	O-RING	IH Superseded by part number: 167266
26.	700717760	[1]	ADAPTER	CAS rubber
27.	700717761	[3]	CLAMP	CAS T bolt
28.	700149743	[1]	MANIFOLD	HFI WA
29.	7721798	[1]	CABLE	CAS TIE nylon
30.	700105144	[1]	GROMMET	CAS TRIM
