凯斯零件查询(8575) - CASE IH MID-SIZE RECTANGULAR BALER (NORTH AMERICA) (1/95-12/00) (02-018) - FLYWHEEL ASSEMBLY Case Agriculture
广数供应链运营团队, 15 02月, 2025，浏览：
363 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| 1. |
700123112
|
[1] |
FLYWHEEL
|
HFI
1/4-28 x 45 Deg. ZERK
|
| 2. |
6855555
|
[1] |
SLEEVE
|
CAS
shear
|
| 3. |
A61447
|
[2] |
ROLLER BEARING,2.1651" ID x 0.9045" Thk
|
CAS
Superseded by part number: 648861
|
| 4. |
700706050
|
[1] |
O-RING
|
CAS
|
| 5. |
700710365
|
[1.5] |
SHIM
|
CAS
flywheel, 0.08/.003
|
| 6. |
700710366
|
[1] |
SHIM
|
CAS
flywheel, 0.13/.005
|
| 7. |
700123118
|
[1] |
HUB
|
CAS
shear
|
| 8. |
700710394
|
[1.5] |
SHIM
|
CAS
CAP flywheel, 0.08/.003
|
| 9. |
700710395
|
[1] |
SHIM
|
CAS
CAP flywheel, 0.13/.005
|
| 10. |
700113045
|
[1] |
LOCKING PLATE
|
CAS
TAB
|
| 11. |
628-16040
|
[2] |
BOLT,Hex, M16 x 2 x 40mm, Cl 10.9, Full Thd
|
CAS
|
| 12. |
700113044
|
[1] |
RETAINING PLATE
|
CAS
CAP retainer
|
| 13. |
700710396
|
[1] |
SHIM
|
CAS
CAP flywheel, 0.25/.010
|
| 14. |
700710397
|
[2] |
SHIM
|
CAS
CAP flywheel, 0.51/.020
|
| 15. |
700710367
|
[1] |
SHIM
|
CAS
flywheel, 0.25/.010
|
| 16. |
700710369
|
[2] |
SHIM
|
CAS
flywheel, 0.51/.020
|
| 17. |
625743C1
|
[2] |
BEARING CUP,90mm OD x 18.5mm W
|
IH
cup
|
| 18. |
219-8
|
[1] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 19. |
700710382
|
[1] |
SEAL
|
CAS
oil
|
| 20. |
413-640
|
[1] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5
|
CAS
Superseded by part number: 87936
|
| 21. |
232-5316
|
[1] |
FLANGE NUT,Flg, 3/8"-16
|
CAS
3/8-16 HFTLN GR/G Superseded by part number: 86521609
|
