现代零件查询R210LC-7 BUCKET CYLINDER(-#3965)EPC Hyundai
广数供应链运营团队, 15 02月, 2025，浏览：
248 次
| Pos. |
Part No |
Qty |
Parts name |
Comments |
| . |
31N6-60110
|
[1] |
CYLINDER ASS'Y
|
|
| -1. |
31Y1-15550
|
[1] |
BUCKET CYL SUB ASSY
|
|
| 1. |
31Y1-15560
|
[1] |
TUBE ASSY
|
|
| 2. |
31Y1-15610
|
[1] |
ROD ASSY
|
|
| 3. |
31Y1-15640
|
[1] |
GLAND
|
|
| 4. |
S732-085030
|
[1] |
BUSHING-DU
|
|
| 5. |
Y191-092000
|
[1] |
RING-SNAP
|
|
| K6. |
Y220-085011
|
[1] |
SEAL-ROD
|
|
| K7. |
Y180-085020
|
[1] |
RING-BACK UP
|
|
| K8. |
Y240-085013
|
[1] |
RING-BUFFER
|
|
| K9. |
Y110-085011
|
[1] |
WIPER-DUST
|
|
| 10. |
Y190-099000
|
[1] |
RING-SNAP
|
|
| K11. |
S631-115004
|
[1] |
O-RING
|
|
| K12. |
S641-115003
|
[1] |
RING-BACK UP
|
|
| 13. |
31YC-23020
|
[1] |
RING-CUSHION
|
|
| 14. |
31Y1-15650
|
[1] |
PISTON
|
|
| K15. |
S632-075004
|
[1] |
O-RING
|
|
| K16. |
S642-075003
|
[2] |
RING-BACK UP
|
|
| K17. |
Y420-125000
|
[1] |
SEAL-PISTON
|
|
| K18. |
Y310-125000
|
[2] |
RING-WEAR
|
|
| K19. |
Y440-125000
|
[2] |
RING-DUST
|
|
| 20. |
31YC-66041
|
[1] |
WASHER-LOCK
|
|
| 21. |
31YC-61243
|
[1] |
NUT-LOCK
|
|
| 22. |
S109-160804
|
[12] |
BOLT-SOCKET
|
|
| 28. |
31YC-11240
|
[2] |
BUSHING-PIN
|
|
| 29. |
Y000-080200
|
[4] |
SEAL-DUST
|
|
| 23. |
31Y1-15660
|
[2] |
BAND ASSY
|
|
| 23-1. |
31Y1-15670
|
[1] |
BAND SUB ASS'Y
|
|
| 23-2. |
31YC-31120
|
[1] |
BAND
|
|
| 23-3. |
S011-100352
|
[2] |
BOLT-HEX
|
|
| 23-4. |
S411-100002
|
[2] |
WASHER-SPRING
|
|
| 23-5. |
31YC-36010
|
[1] |
CLAMP-PIPE
|
|
| 23-6. |
S015-120502
|
[1] |
BOLT-HEX
|
|
| 23-7. |
S411-120002
|
[1] |
WASHER-SPRING
|
|
| 24. |
31Y1-15680
|
[1] |
PIPE ASSY-R
|
|
| 25. |
31Y1-15690
|
[1] |
PIPE ASSY-B
|
|
| K26. |
Y171-019004
|
[2] |
O-RING
|
|
| 27. |
S107-100454
|
[8] |
BOLT-SOCKET HEAD
|
|
| K. |
31Y1-15700
|
[1] |
SEAL KIT
|
|
