纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (6.701[01]) - BATTERY - SEAT AND SUPPORT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
366 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 79062587 | [2] | DRY BATTERY | LEC- IN ALTERNATIVE Superseded by part number: 75128468 |
| 1. | 71421589 | [2] | DRY BATTERY | LEC- IN ALTERNATIVE 160AH Superseded by part number: 73325166 |
| 2. | 79088092 | [1] | CONTAINER | LEC |
| 3. | 79010787 | [2] | PLATE | LEC |
| 4. | 79084347 | [2] | BRACKET | LEC |
| 5. | 79014057 | [2] | SPACER | LEC |
| 6. | 11106631 | [2] | SCREW,Hex, M10 x 35mm, Cl 10.9, Full Thd | LEC Superseded by part number: 86624978 |
| 7. | 11106031 | [2] | BOLT,Hex, M10 x 1.5 x 20mm, Cl 10.9 | LEC |
| 8. | 12626231 | [4] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 9. | 11701721 | [2] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 10. | 16043631 | [4] | SCREW,Hex, M8 x 25mm, Cl 10.9, Full Thd | BHB Superseded by part number: 43234 |
| 11. | 14496531 | [4] | WASHER,8.4mm ID x 17mm OD x 1.6mm Thk | LEC Superseded by part number: 86624184 |
