| 1. |
515-23254
|
[2] |
CLAMP,1", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 9827902, 72187281
|
| 2. |
515-23190
|
[4] |
CLAMP,3/4", Insul, 3/8" Bolt
|
CAS
Line Superseded by part number: 86624005
|
| 3. |
6553804
|
[2] |
SPACER
|
HFI
|
| 4. |
113-250
|
[2] |
BOLT,Hex, 3/8" - 16 x 2-1/2", Gr 5, Full Thd
|
CAS
|
| 5. |
329-286
|
[4] |
FLANGE NUT,Flg, 3/8"-16, G8
|
CAS
|
| 6. |
873018
|
[4] |
BOLT,5/16" - 18 x 3 3/4", Gr 5
|
HFI
5/16-18 x 3-3/4 C
|
| 7. |
495-61034
|
[4] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
wide plain, 5/16
|
| 8. |
231-5145
|
[4] |
SERRATED NUT,Flg, USR, 5/16"-18
|
CAS
Superseded by part number: 72187067, 145458
|
| 9. |
700133097
|
[2] |
SUPPORT
|
HFI
SHIELD
|
| 10. |
700150595
|
[1] |
SHIELD
|
HFI
flywheel
|
| 11. |
700150596
|
[2] |
STRAP
|
HFI
SHIELD, support
|
| 12. |
121-115
|
[6] |
SERRATED BOLT,Hex, 5/16" - 18 x 3/4"
|
CAS
|
| 13. |
700150591
|
[5] |
CHANNEL
|
HFI
mounting
|
| 14. |
121-237
|
[2] |
SERRATED BOLT,Hex, 3/8" - 16 x 1 1/4, Spcl
|
CAS
3/8-16 x 1-1/4 HFS GR8 Superseded by part number: 87327172
|
| 15. |
700717865
|
[1] |
HOSE
|
CAS
hydraulic
|
| 16. |
700718207
|
[1] |
HOSE
|
CAS
hydraulic
|
| 17. |
218-5123
|
[1] |
ELBOW,90 Degree Elbow, 1-1/16" - 12 Male JIC x 7/8" - 14 Male ORB
|
CAS
hydraulic, 90 Deg. Superseded by part number: 144123
|
| 18. |
700150589
|
[1] |
SUPPORT
|
HFI
blower
|
| 19. |
121-108
|
[9] |
BOLT,Hex Flg, 5/16"-18 x 1 1/4", Serr
|
CAS
5/16-18 x 1 HWHMS
|
| 20. |
496-21034
|
[3] |
WASHER,11/32" x 11/16" x 0.89", HDN
|
CAS
Superseded by part number: 86637953
|
| 21. |
232-5315
|
[10] |
FLANGE NUT,Flg, 5/16"-18
|
CAS
5/16-18 HFTLN GR/G
|
| 22. |
700149723
|
[1] |
STRAP
|
HFI
support
|
| 23. |
700701753
|
[1] |
HYD CONNECTOR
|
CAS
hydraulic, Includes: Ref. 24
|
| 24. |
738484
|
[1] |
O-RING
|
IH
Superseded by part number: 167266
|
| 25. |
700717760
|
[1] |
ADAPTER
|
CAS
RUBBER
|
| 26. |
700717761
|
[3] |
CLAMP
|
CAS
T BOLT
|
| 27. |
700149743
|
[1] |
MANIFOLD
|
HFI
WA
|
| 28. |
7721798
|
[1] |
CABLE
|
CAS
TIE nylon
|
| 29. |
700105144
|
[1] |
GROMMET
|
CAS
trim
|
