| 1. |
413-820
|
[4] |
BOLT,Hex, 1/2" - 13 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 72187215, 87670
|
| 2. |
80679
|
[6] |
LOCK WASHER,1/20.507 CST ZND
|
NH
|
| 3. |
425-108
|
[4] |
NUT,1/2" - 13, Gr 5
|
CAS
Superseded by part number: 280431
|
| 4. |
705541
|
[2] |
WASHER,0.53" ID x 1.06" OD x 0.14" Thk
|
CAS
hardened plain, 1/2
|
| 5. |
700123351
|
[1] |
FUNNEL
|
CAS
FRAME WA knotter
|
| 6. |
164-102
|
[4] |
HEX SOC SCREW,FLAT, #10 - 32 x 1/2"
|
CAS
#10-32 x 1/2 HSFCHCS
|
| 7. |
700707700
|
[8] |
BALL BEARING,6.48 mm ID x 31.75 mm OD x 13.08 mm
|
CAS
roller Superseded by part number: 700737442
|
| 8. |
866566
|
[4] |
FASTENER,#10 - 32 x 9/16"
|
CAS
special, #10-32
|
| 9. |
700123374
|
[1] |
ARM
|
CAS
ASSEMBLY, Includes: Ref. 6, 7 and 8
|
| 10. |
858308
|
[1] |
SPRING
|
CAS
extension
|
| 11. |
495-81205
|
[13] |
WASHER,32.54mm ID x 50.8mm OD x 1.7mm Thk
|
CAS
1-1/4 x 18 gauge NRMB
|
| 12. |
700113342
|
[2] |
SUPPORT
|
CAS
bearing
|
| 13. |
432-1028
|
[2] |
COTTER PIN,5/32" x 1 3/4"
|
CAS
Superseded by part number: 281075
|
| 14. |
D23692
|
[2] |
SNAP RING,#100, Ext, Crescent
|
CAS
Ring, Snap, #100, Ext, Crescent
|
| 15. |
219-8
|
[2] |
LUBE NIPPLE,1/4" - 28 NPTF
|
CAS
Superseded by part number: 87414
|
| 16. |
195-2103
|
[11] |
WASHER,1 1/16" x 1 1/2" x .065"
|
CAS
1 x 18 gauge NRMB
|
| 17. |
219-90
|
[2] |
LUBE NIPPLE,45 Degree Elbow, 1/4" -28 NPTF
|
CAS
1/4-28 x 45 Deg. ZERK Superseded by part number: 87569
|
| 18. |
700123376
|
[1] |
FUNNEL
|
CAS
FRAME WA tension arm
|
| 19. |
6523799
|
[8] |
BUSHING
|
CAS
|
| 20. |
700150609
|
[4] |
ARM
|
HFI
ASSEMBLY TENSION, Includes: Ref. 23, 24, 25 and 7
|
| 21. |
700712484
|
[1] |
SPRING
|
CAS
extension
|
| 22. |
758482
|
[4] |
TENSION SPRING
|
CAS
extension
|
| 23. |
700150610
|
[4] |
ARM
|
HFI
tension
|
| 24. |
163-14
|
[4] |
SCREW,Hex Wshr Hd, 1/4" - 20 x 1"
|
CAS
1/4-20 x 1 HWHMS
|
| 25. |
1703354
|
[4] |
NUT
|
IH
1/4-20 HFTLN GR/G
|
| 26. |
413-520
|
[8] |
BOLT,Hex, 5/16" - 18 x 1-1/4", Gr 5
|
CAS
Superseded by part number: 87657
|
| 27. |
492-11031
|
[8] |
LOCK WASHER,5/16"
|
CAS
Superseded by part number: 83990583
|
| 28. |
425-105
|
[8] |
NUT,5/16"-18, G5
|
CAS
Superseded by part number: 9635082, 72187221
|
| 29. |
700714985
|
[1] |
SPRING
|
CAS
extension
|
| 30. |
433-816
|
[4] |
CARRIAGE BOLT,Sq Nk, 1/2" - 13 x 1", Gr 5
|
CAS
1/2-13 x 1 RHSNB Superseded by part number: 280486
|
| 31. |
231-5148
|
[4] |
FLANGE NUT,Flg, USR, 1/2"-13
|
CAS
Superseded by part number: 72187069, 86512371
|
| 32. |
219-17
|
[2] |
LUBE NIPPLE,3/16" NPTF
|
CAS
Push Superseded by part number: 80722
|
| 33. |
425-118
|
[2] |
NUT,1/2"-20, G5
|
CAS
Superseded by part number: 280963
|
| 34. |
8050866
|
[2] |
CAM FOLLOWER
|
CAS
roller, cam Superseded by part number: 84393376
|
| 35. |
700123370
|
[1] |
SHAFT
|
CAS
finger twine
|
| 36. |
700123381
|
[2] |
ROD
|
CAS
MONITORING
|
| 37. |
495-61034
|
[4] |
WASHER,0.34" ID x 0.88" OD x 0.06" Thk
|
CAS
wide plain, 5/16
|
