纽荷兰零件查询(FD175) - CRAWLER DOZER (N.A. VERSION)(S/N 061640 & AFTER) (1/93-) (3.440[03]) - REAR EQUIPMENT PIPING New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
683 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 76007732 | [4] | HALF-FLANGE | LEC |
| 2. | 11107431 | [1] | SCREW,Hex, M10 x 1.5 x 60mm, Cl 10.9 | LEC Superseded by part number: 86508619 |
| 3. | 79084821 | [2] | CLAMP | LEC |
| 4. | 12626231 | [2] | WASHER,10.2mm ID x 25mm OD x 3mm Thk | LEC |
| 5. | 11701721 | [1] | NUT,M10, Cl 10 | LEC Superseded by part number: 17038131 |
| 6. | 79114137 | [2] | FLEXIBLE HOSE | LEC |
| 7. | 76032259 | [1] | RIGID TUBE | LEC |
| 8. | 76032260 | [1] | RIGID TUBE | LEC |
| 9. | 14420131 | [10] | HEX SOC SCREW,M10 x 1.5 x 25mm, Cl 10.9, Full Thd | LEC |
| 10. | 70924110 | [4] | O-RING | LEC3,53X24,99 Superseded by part number: 98458442 |
| 11. | 79109694 | [1] | FLANGE | LEC |
| 12. | 79050056 | [4] | FLANGE | LEC Superseded by part number: 71404407 |
| 13. | 14420231 | [8] | HEX SOC SCREW,M10 x 1.5 x 30mm, Cl 10.9, Full Thd | LEC |
| 14. | 70931640 | [2] | O-RING,0.07" Thk x 0.926" ID, -21, Cl 6, 90 Duro | LEC1,78X23,52 Superseded by part number: 87473574 |
